I/O Connector - Advantech ITA-3650E Series User Manual

Table 2.6: AMPR1: R Sound Channel Amplifier Switch
Closed Pins
1-2,4-5
2-3,5-6
2.4

I/O Connector

VGA
Expansion bracket(Op onal, such as LPT/PS2/DIO)
ITA-3650E Series User Manual
Setting
R sound channel amplifier switch ON (default)
R sound channel amplifier switch OFF (default)
HDMI
USB2.0
USB3.0+LAN
2 x LAN
10
AUDIO 9~36Vdc
COM1/2
COM3~8
1x PCIe x 8 or 1 x PCI
1 x PCI
POWER
BUTTON
DIO
