Advantech ITA-2230S Startup Manual

ITA-2230S Intel® Core™ i7 Fanless 2U Rackmount
System with 2 ITAM Slots and Standard PCI/PCIE Slot
Startup Manual
Packing List
Before installing the board, please ensure that the following
items have been shipped:
1. 1 x ITA-2230S IPC
2. 1 x ITA-2230S Accessory Box
3. 1 x ITA-2230S Warranty Card
If any of the above items are missing or damaged, please
contact your distributor or sales representative immediately.
Note: Adobe Acrobat Reader is required to view PDF
files. Adobe Acrobat Reader can be downloaded at www.
adobe.com/Prodindex/acrobat/readstep2.html (Acrobat is a
trademark of Adobe).
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com.tw/support/default.
aspx
This manual is for the ITA-2230S Series.
Part No. 200K223050
Printed in China
Specifications
Standard Function
• Chip & Chipset: Intel Core™ i7-3555LE processor and
QM77 Chipset
• BIOS: AMI SPI 64 Mb
• Memory: Onboard DDR3 1600 up to 4GB
• Display:
Intel HD4000, Frequency 550MHz,
Share system memory up to 512MB SDRAM
• Dual display mode:
Resolution of single display up to 2048 x 1536,
1 x DVI-D, 1 x DVI-I
• Storage:
- 1 x 3.5"HDD or 2 x 2.5"HDD
- 1 x Full Size mSATA
• Expansion slot:
- 2 x ITAM slot
- 1 x PC104+
- 1 x Mini PCIe slot
- 1 x PCI slot
- 1 x PCIE x4 slot
System Specifications
• Ethernet: 2 x 10/100/1000M Ethernet
• USB: 4 USB 3.0, 3 USB 2.0
• DVI: 1 x DVI-D, 1 x DVI-I
• Serial port: 2 DB9 ports, support RS-232/422/485
• Digital I/O: 1 x 8-ch TTL GPIO
• Audio: 1 Speaker Out (support 2x4W Amp),1 Mic-in
• ITAM module (optional): ITAM modules can be optional
inserted into three ITAM slots to make LAN or COM ports
up to 24 additional ports for expansion needs.
Mechanical and Environment
• Dimensions (W x H x D): 427 x 88 x 325 mm
• Voltage input: AC 100-240 or DC 110V
• Working temperature:
- 0 -40° C (32 ~ 104° F , with HDD)
- 25 - 60° C (-13 ~ 140° F, with SSD)
• Weight:
- Single Power: 7.7 kg
- Dual Power: 8 kg
1st Edition
July 2015
ITA-2230S Startup Manual 1
