Jumper And Connector Locations - Advantech ITA-3650T Series User Manual

2.3.2

Jumper and Connector Locations

The board features a number of connectors and jumpers that allow users to configure
the system according to the usage application. The table below lists the function of
each connector and jumper. The locations of jumpers and connectors on the board
are shown in Figures 2.3 and 2.4.
Table 2.1: Jumpers and Connectors
Label
JCMOS1
AMPL1
AMPR1
PSON1
VCCGPIO1
SATA1
SATA2
SATA3
SATA_PWR1
SATA_PWR2
DP1
LPT1
USB1
COM3456
KBMS
M-SATA
MiniPCIe
ITA-3650T Series User Manual
Function
Clear CMOS settings
L sound channel amplifier switch
R sound channel amplifier switch
AT/ATX mode selection
GPIO voltage selection
SATA data interface 1
SATA data interface 2
SATA data interface 3
SATA power interface 1
SATA power interface 2
DP digital display interface 1
LPT interface
USB interface 1
COM port interface
Keyboard/mouse
mSATA storage card interface
Mini PCIe module interface
10
