2.4.3

VGA Connector

ITA-3650E offers one D-sub 15-pin female connector.
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
2.4.4

DIO Connector

ITA-3650E provides a DIO connector that needs cabling.
Pin
1-12
13
14-25
2.4.5

Audio in Connector

ITA-3650E provides an integrated Mic-in/speaker out audio connector.
ITA-3650E Series User Manual
Signal Name
Red
Green
Blue
NC
GND
GND
GND
GND
+5V
GND
NC
DDC-DATA
H-SYNC
V-SYNC
DDC-CLK
Signal Name
Digital input (input)
GND
Digital output (output)
