ITA-2211 Intel® Atom™ E3845 Fanless 2U Rackmount
System with 3 ITAM Slots
Startup Manual
Packing List
Before installing the board, please ensure that the following
items have been shipped:
1. 1 x ITA-2211 IPC
2. 1 x ITA-2211 Accessory Box
3. 1 x ITA-2211 Warranty Card
If any of the above items are missing or damaged, please
contact your distributor or sales representative immediately.
Note: Adobe Acrobat Reader is required to view PDF
files. Adobe Acrobat Reader can be downloaded at www.
adobe.com/Prodindex/acrobat/readstep2.html (Acrobat is a
trademark of Adobe).
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com.tw/support/default.
aspx
This manual is for the ITA-2211 Series.
Part No. 2001221110
Printed in China
Specifications
Standard Function
• Chip & Chipset: Intel Atom™ E3845 processor
• BIOS: AMI SPI 64 Mb
• Memory: Onboard DDR3 1600 up to 4GB
• Display:
Intel Gen 7, Frequency 543 MHz,
Share system memory up to 256 MB SDRAM
• Dual display mode:
Resolution of single display up to 2048 x 1536,
1 x VGA, 1 x DVI-I
• Storage:
- 1 x 3.5"HDD or 2 x 2.5"HDD
- 1 x Full Size mSATA
• Expansion slot:
- 3 x ITAM slot
- 1 x PC104+
- 1 x Mini PCIe slot
System Specifications
• Ethernet: 2 x 10/100/1000M Ethernet
• USB: 1 USB 3.0, 6 USB 2.0
• DVI: 1 x VGA, 1 x DVI-I
• Serial port: 2 DB9 ports, support RS-232/422/485
• Digital I/O: 1 x 8-ch TTL GPIO
• Audio: 1 Speaker Out (support 2x4W Amp),1 Mic-in
• ITAM module (optional): ITAM modules can be optional
inserted into three ITAM slots to make LAN or COM ports
up to 24 additional ports for expansion needs.
Mechanical and Environment
• Dimensions (W x H x D): 427 x 88 x 325 mm
• Voltage input: AC 100-240 or DC 110V
• Working temperature:
- 0 -40° C (32 ~ 104° F , with HDD)
- 25 - 60° C (-13 ~ 140° F, with SSD)
• Weight:
- Single Power: 7.7 kg
- Dual Power: 8 kg
1st Edition
August 2015
ITA-2211 Startup Manual 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the ITA-2211 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Advantech ITA-2211

  • Page 1 ITA-2211 Intel® Atom™ E3845 Fanless 2U Rackmount System with 3 ITAM Slots Startup Manual Packing List Specifications Standard Function Before installing the board, please ensure that the following items have been shipped: • Chip & Chipset: Intel Atom™ E3845 processor 1.
  • Page 2: Jumpers And Connectors

    Setting Pins Signal Name Signal Name Signal Name Default* DATA- Clear CMOS setting DATA+ *Default setting Default Clear CMOS PSON1: Power On Mode Setting Pins Setting AT mode ATX mode* *Default setting AT Mode ATX Mode 2 ITA-2211 Startup Manual...
  • Page 3 Pins Signal Name Red(Red) GPIO0 GPIO4 Green(Green) GPIO1 GPIO5 GPIO2 GPIO6 Blue(Blue) GPIO3 GPIO7 DDC-DATA H-SYNC V-SYNC DDC-CLK Audio: Audio In Pins Signal Name Pins Signal Name AUD_GND LOUT_L MIC1_L LOUT_JD MIC_JD AUD_GND AUD_GND LOUT_R MIC_R ITA-2211 Startup Manual 3...
  • Page 4 Check whether the rivet of the module is fully inserted LED Status: 1000M Green (top left LED) 3. Fix ITAM Module upon ITA-2211 system with screws in front and rear both side. 100M Orange (top left LED) No lights...
  • Page 5: Safety Instructions

    The sound pressure level at the operator’s position does not exceed 70 dB (A) as per the IEC 704-1:1982 specifica- tions. DISCLAIMER: These instructions are provided according to the IEC 704-1 standard. Advantech assumes no responsi- bility for the accuracy of this manual. ITA-2211 Startup Manual 5...
  • Page 6 Board Jumper Setting Drawing Mainboard Jumpers and Connectors Location SATA_PWR1 SATA_PWR2 LPT1 SATA2 SATA1 VCCGPIO1 MSATA1 PSON1 SODIMM1 JCMOS1 MINIPCIE1 Backplane Jumpers and Connectors Location PC104_ISA VIO1 PC104_PCI ITAM Slot1 ITAM Slot2 ITAM Slot3 6 ITA-2211 Startup Manual...
  • Page 7: System Diagram

    SL OT 1 DVI D DVI D Reset Button Power Button COM LED IT AM Serial Port x 2 VGA RJ45 x 2 Power Module HDD LED LAN LED USB2.0 x 4 Alert LED USB3.0 x 1 ITA-2211 Startup Manual 7...
