Advantech ITA-5710 Series Startup Manual

ITA-5710 Series Intel@ Atom D525 Fanless Compact Sys-
tem with 2 x M12 GigaLAN, 2 x M12 USB and Dual Display
Fully Compliant with EN 50155
Startup Manual
Packing List
Before you begin installing your IPC, please make sure that
the following items have been shipped:
1. 1 x ITA-5710 series IPC
2. 1 x Accessary box
3. 1 x Warranty card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note 1: For detailed contents of ITA-5710, please refer
to information on the enclosed CD-ROM (in PDF
format).
Note 2: Acrobat Reader is required to view any PDF
file.Acrobat Reader can be downloaded at:
www.adobe.com/Products/acrobat/readstep2.
html (Acrobat is a trademark of Adobe)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com
This manual is for the ITA-5710 Series.
Part No. 200K571010
Print in China
Specifications
Standard Functions
• Chip and chipset: Intel Atom processor D525 and Intel
ICH8M chipset
• BIOS: AMI SPI 16 MB Flash
• Memory: Onboard 2 GB DDR3 800/667 memory
• Display: Embedded Gen3.5+GFX Core, Frequency 400
MHz. Shared system memory up to 256 MB SDRAM
• Dual display mode:
- Resolution of single display up to 2048 x 1536
- Resolution of dual display up to 1366 x 768
• CF interface: Supports 1 CompactFlash socket
• Expansion slot: Support 2 mini-PCIe slot/1 PCI slot/1
PCIe x1 slot
System Specifications
• Ethernet: 2 x 10/100/1000M Ethernet, M12 A-coded(F)
8-pin (Controller chip: Intel i210-IT)
• USB:
– 2 x USB2.0 with M12 A-coded(F) 4-pin
– 6 x USB2.0 with Type A
• VGA: 2 VGA connctors
• Serial port: 2 serial ports, with RS-232/422/485
• Audio: 1 speaker out (supports 2-ch 4w speaker), 1 line
in; DB9 connector
Mechnical and Environment
• Dimensions (W x H x D): 210 x 129 x 240 mm
• Voltage input: DC 24V/48V/72V/110V, compliance with
EN50155
• Operating temperature:
• Weight: 4.5 kg
1st Edition
June 2014
253 x 133 x 240 mm (with ears)
-40 ~ 60° C (-40 ~ 140° F)
ITA-5710 Startup Manual 1
