11.2 Specifications of the Basic Device
11.2.1 Weight and Dimensions
17 March 2021
Technical Data and Specifications
Mass base unit
Description
Individual unit with 25 mm throw
Individual unit with 50 mm throw
Exterior dimensions for individual unit
Description
Width
Depth
(door closed)
Depth
(with door open)
Height
Height
(with rubber feet)
Height
(with 13 cm base)
Height
(with 31 cm base)
Exterior dimensions for two units stacked
Description
Width
(without side-mounted cooling system)
Width
(with side-mounted cooling system)
Depth
Height
(with 31 cm base)
Exterior dimensions for three units stacked
Description
Width
Depth
Height
(without top cooling system, with 13 cm
base)
Height
(with top cooling system, with 13 cm base)
Multitron Standard - Operating Manual
Value Unit
106 kg
114 kg
Value Unit
1070 mm
870 mm
1160 mm
530 mm
550 mm
665 mm
845 mm
Value Unit
1070 mm
1315 mm
870 mm
1375 mm
Value Unit
1070 mm
870 mm
1760 mm
2000 mm
