Box For Microtitre Plates - Infors HT Multitron Standard Operating Manual

4.3 Box for Microtitre Plates

1
6
5 4 3
17 March 2021
The test tube holders adhere extremely strongly to the Sticky Stuff,
so that water has to be sprayed underneath the edge of the
holder with a syringe in order to remove them. This is done to pre-
vent damage to the holder or the tray.
Overview
The box for microtitre plates is used for low-vapour cultivation of mi-
crotitre plates and deep well plates. It protects cultures from drafts in
the incubation chamber and also offers a stable container in which
cultures can be transported.
The box for microtitre plates consists of an aluminium container with
a removable lid into which a replaceable paper filter is integrated. A
microtitre insert with screw-mounted pins is used for mounting mi-
crotitre plates and deep well plates.
For shaking, the box for microtitre plates can be screwed onto a uni-
versal table tray or placed on the Sticky Stuff adhesive matting.
Structure
2
1
2
3
4
5
6
Mounting the box for microtitre plates
The box for microtitre plates is mounted on the table by means of
four Phillips-head screws. When delivered, the fastening screws are
covered with plastic cap nuts. These must be removed prior to instal-
lation.
Alternatively, the box for microtitre plates can be placed on the Sticky
Stuff adhesive matting. In this case, all fastening screws must be re-
moved to avoid damaging the adhesive matting.
During installation, ensure that the tray is always loaded evenly.
ATTENTION
Filter
Top plate
Microtitre insert
Quickload spacers
Container
Filter washer
Multitron Standard - Operating Manual
Accessories
Page 43 of 114
