Rectifying Faults

7.3 Rectifying Faults
7.3.1

Replacing Fuses

Procedure
7.3.2

Replacing the Lighting Element for the Interior Lighting

Procedure
Page 90 of 114
INFORMATION
The fuses may only be replaced by fuses of the same rating. For in-
formation concerning the requirements for the fuses see chapter
7.3.1 "Replacing Fuses", page 90.
To replace a defective fuse, proceed as follows:
1. Turn off the device and pull out the mains plug.
2. Unlock the plug for the fuses by pressing together the two flaps
and pull out the plug at the same time.
3. Remove the defective fuse.
4. Insert a new fuse with the correct number of Amperes.
5.
Push the plug as far back in the opening as possible until it
snaps in.
6.
Re-establish the power supply to the device.
To replace a defective lighting element, proceed as follows:
INFORMATION
For information on the lighting specifications, see chapter 11.2.3
"Interior Lighting", page 103.
1. Open the device door all the way.
2. Turn off the power switch and pull out the plug.
3. Slide the interior lighting cover to the side.
4. Remove the defective lighting element from the fixture.
5. Plug a new lighting element into the fixture.
6. Slide the cover back over the interior lighting.
17 March 2021
