Racelogic VBOX Touch User Manual page 95

3. It is also possible to change the 3rd tracked constellation between Beidou and Glonass if required by navigating to
'GNSS Selection' within the 'General Settings' screen. More information on this is
Checking You Have RTK Lock
The status of the DGNSS lock within a VBOX Touch RTK can be seen on screen via the Satellite Icon.
The status is also available within the GPS Status area of the
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/06_-_VBOX_Touch_RTK
Flashing Red - No
satellite lock
Solid Orange - RTK Float
Diagnostics menu.
available here.
Solid Green - Standalone
positional accuracy; Code
Diff/SBAS positional
accuracy
Solid Purple - RTK Fixed
95
