Left Side - Racelogic VBOX Touch User Manual

Features
• 4.3" TFT daylight readable capacitive touch screen
• 4 x high brightness LED Indicators
• Built-in applications such as performance testing,
lap timing and speedometer
• Python-based applications, ideal for solving user-
specific testing needs
Connectors
More detailed connector information can be found on the

Left Side

SD Card
VBOX Touch logs data via an SD card. Dependent on the
Settings area, the unit will either log continuously or when movement is detected (default). More information on this is
available here.
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/01_-
• Removable protective rubber cover included
• 10 Hz GNSS receiver with internal patch antenna
• SMA connector for external GNSS antenna
(overrides the internal antenna when connected)
• Available in an RTK variant for receiving RTK
correctional signals for centimetre-level positional
accuracy
PIN OUTS page.
Logging Strategy selected within the General
_VBOX_Touch_Introduction
3
