VBOX Touch - PIN OUTS
Connector 1 - GNSS Antenna
PIN
Centre
Chassis
Right side view of VBOX Touch
I/O
I
I
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/08_-
Function
RF Signal/Power for active antenna
Ground
_VBOX_Touch_Technical_Properties/VBOX_Touch_-_PIN_OUTS
