Logging Status
The Record Icon
will show when the unit is logging data to the SD card.
IMPORTANT – The SD card shouldn't be removed when the Record Icon is on as you may lose data.
SD Status
The SD Card Icon displays the status of the recording media. When an SD card has been inserted and has free space,
it will display as green
. When no SD card is detected or the media is full, the icon will display as red
.
Tapping on the icon when green will manually start or stop logging data, overriding the
Sats Status
The Satellite Icon displays the current GNSS status. More information on the different GNSS states can be found here.
Flashing Red - No
satellite lock
Solid Orange - RTK Float
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/03_-
Configured Logging Strategy.
Solid Green - Standalone
positional accuracy; Code
Diff/SBAS positional
accuracy
Solid Purple - RTK Fixed
