Connector 4 - CAN / SERIAL (Lemo 5 PIN)
Isolated CAN bus with active 120 ohm terminating resistors
PIN
1
2
3
4
5
Chassis
I/O
I/O
I/O
I
I
I/O
O
I
I/O
I/O
I
I
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/08_-
Function
CAN High
CAN Low
Power
Ground
Function
RS232 Tx
RS232 Rx
CAN High
CAN Low
Power
Ground
_VBOX_Touch_Technical_Properties/VBOX_Touch_-_PIN_OUTS
