• Output Mode: If required, choose the output mode of the serial port, selectable as 'VBOX Stream', 'Lap Timing' or
'Disabled' (default). VBOX Stream allows you to connect VBOX Touch with a computer using an RLCAB001 and
conduct online testing with VBOX Test Suite, more information on this is
option will output lap timing parameters.
• Baud Rate: Displays the serial output baud rate, set as 115200 kbit/s.
RTK Input
VBOX Touch RTK units only.
RTK input is available on the
side of the Serial Port Settings.
• NTRIP Mode: For use with a
When 'Enabled', VBOX Touch will output a GGA NMEA message and receive RTK corrections via an NTRIP
modem connected to the
Station solution, this option should be Disabled.
Note: The external antenna should be used when receiving RTK corrections.
• DGPS Baud Rate: Control the DGNSS serial baud rate, selectable as 38400 kbit/s (default) and 115200 kbit/s. If
you are using a VBOX NTRIP
Module with a Static Base
or 38400 kbit/s for a Satel grey boxed radio. Tap the button to change the setting.
The RTK correction status of the unit can be seen within the
is indicated by the colour of the
bottom CAN/Serial port
VBOX NTRIP Modem.
bottom CAN/Serial port. If you are intending to receive corrections via a
Modem, this setting should be 115200 kbit/s. If you are using a Telemetry Radio
Station, this setting should be either 115200 kbit/s for a Racelogic blue boxed radio
Satellite Icon.
