Racelogic VBOX Touch User Manual page 54

Note: Lap timing gates are bi-directional and can be triggered when passing through in either direction.
Lap Timing Mode Overview
There are 2 different Lap Timing screens which can be accessed by selecting the Forward
and Back
arrows on the bottom right of the screen or by swiping the screen left or right.
Lap Timing - Main Screen
This is the default lap timing screen and displays live Lap Timing information in relation to a set
Separate Start and Finish Lines or a Standing Start and
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_-
Separate Finish Line, and a
_VBOX_Touch_Display_Modes/VBOX_Touch_-_Lap_Timing_Mode
Start/Finish Line,
Reference Lap.
54
