Button
on the bottom left of the screen to return the Settings
screen without saving.
Note: If you press the Select button when you are not in
the vicinity of a known track, the unit will display a NO
LIST AVAILABLE message.
If the layout is changed, the LEDs will briefly flash
The layout will be remembered after each power cycle if it is determined to be local to the detected location.
Note: When the selected track is changed, all existing lap timing values will be cleared and the new lap timing gates will
be used.
Set Start/Finish Gate
Selecting the Set Start Gate option within the
overwriting the line detected within the circuit layout. If you are defining a separate
Start Line only. More information about manually setting a start/finish line can be found above.
Note: The vehicle must be moving >0.8 km/h and the unit have satellite lock to set a Start/Finish Line.
Set Finish Gate
Selecting the Set Finish Gate option within the
overwriting the finish line detected within the circuit layout. A separate finish line must be set if you are using
Start Mode. More information about manually setting Finish line can be found above.
green
Lap Timing Settings
Lap Timing Settings
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_-
twice and the unit will emit an audible confirmation notification.
manually set a start/finish line when moving,
will manually set a Finish line when moving,
_VBOX_Touch_Display_Modes/VBOX_Touch_-_Lap_Timing_Mode
Finish Line, this gate will act as the
Standing
