Racelogic VBOX Touch User Manual page 104

Connector 2 - D IN / PPS (Lemo 3 PIN)
Digital In and PPS Connector
PIN
1
2
3
Connector 3 - CAN / SERIAL (Lemo 5 PIN)
Isolated CAN bus with active 120 ohm terminating resistors
PIN
1
2
I/O
I
O
I
I/O
O
I
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/08_-
Function
Ground
PPS
Event/Brake Trigger
Function
RS232 Tx
RS232 Rx
_VBOX_Touch_Technical_Properties/VBOX_Touch_-_PIN_OUTS
