is used to select the key and appears whenever a key selection is required. The
page which appears is the one which was current when programming mode was
entered.
If, having entered programming mode, you find that the required key is not on
the page which is displayed, go to the page selection menu. This indicates (and
puts the cursor on to) the page number which was selected. It also offers the
facility to change the current page number if necessary.
To see both the page number and its content simultaneously, go to normal
operation as described in the operational information.

MASTER VOLUME CONTROL

The master volume control is set from the main page. The scroll buttons will
change the current page if pressed momentarily but if pressed and held will
change the volume setting.
Press and hold one of the scroll buttons until volume bars change then use the
scroll buttons to adjust the master volume as indicated by the volume bars until
the required level is reached.

BELTPACK PROGRAMMING - MENU MAP

On the menu map below, the flow is downwards and to the right unless indicated
otherwise.

MAIN PROGRAMMING MENU

This is the main menu for programming the Beltpack.
You reached this menu by holding both the UP and DOWN keys pressed for at
least 3 seconds. To return to normal operation, select Exit (the Up arrow on the
display) and press pushbutton C.
To navigate around any menu, use the UP and DOWN scroll buttons to
highlight the required item (the highlighted item is shown in inverse video).
Then press Pushbutton C (effectively the "Reply/Answerback" key in normal
mode or "Enter" key when in Program Mode) to implement the selection.
