3. Hardware Setup

Installation Requirements

Be sure that the ambient temperature is within the range specified in the installation environment
requirement by making space between the product and device that generates heat or exhaust air.
Installed angle which is recommended
Installed angle of this product which is recommended is -45° - 45°. Except for that, the temperature
specification of this product might not be filled.
Figure 3.11. Installed angle which is recommended
CAUTION
Even if the ambient temperature is within the usage range, if the product is installed near devices that
generate high temperatures, the product may experience the effects of radiation which will cause its
temperature to rise and may lead to product malfunctions.
