Super IO Configuration

Configure the operation settings for Super IO.
Advanced
Super IO Configuration
Super IO Chip
▶
Serial Port A Configuration
▶
Serial Port B Configuration
▶
T.P. Serial Configuration
Figure 5.5. Super IO Configuration
Table 5.8. Super IO Configuration
Item
Serial Port A
Configuration
Serial Port B
Configuration
T.P. Serial
Configuration
Table 5.9. Serial Port A Configuration
Item
Serial Port
Change Settings
PT-956SxX Series User's manual
Aptio Setup Utility - Copyright (C) 20xx American Megatrends, Inc.
NCT6106D
Version x.xx.xxxx. Copyright (C) 20xx American Megatrends, Inc.
Option
Refer to Table 5.9.
Refer to Table 5.10.
Refer to Table 5.11.
Option
Disabled
Enabled
IO=3F8h; IRQ=4;
IO=2A0h; IRQ=3,4,5,6;
IO=2E8h; IRQ=3,4,5,6;
IO=2F8h; IRQ=3,4,5,6;
IO=3E8h; IRQ=3,4,5,6;
IO=3F8h; IRQ=3,4,5,6;
IO=2D0-2F8h; IRQ=3,4,5,6;
→←:Select Screen
↑↓:Select Item
Enter:Select
+/-:Change Opt.
F1:General Help
F2:Previous Values
F3:Load Defaults for Win7
F4:Save & Exit
F5:Load Defaults for Win10
ESC:Exit
Description
-
-
-
Description
Configure the operation settings for serial
port A.
Do not change this setting.
