  • Page 1 IPC Series PANEL-PC PT-S2000HX/HXC/LX/LXC Series User’s Manual CONTEC CO., LTD.

  • Page 2: Product Configuration List

    Contact Product guide (this sheet) The user's manual for this product is available as a PDF file through CONTEC’s Web site. The user's manual provides such information as hardware settings, functions for each component, and BIOS settings. Refer to it as necessary.

  • Page 3: Product Configuration Image

    No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this document.

  • Page 4: Table Of Contents

    Table of Contents Check Your Package ..........................ii ◆Product Configuration List ......................ii ◆Product Configuration Image ....................iii Copyright ............................iii Trademarks ............................iii Table of Contents ..........................iv 1. INTRODUCTION About the Product ..........................7 ◆Features............................. 8 ◆Supported OS ..........................8 Customer support ..........................
  • Page 5 4. BIOS SETUP Introduction ............................28 Starting Setup ............................ 28 Using Setup ............................29 ◆Getting Help ........................... 29 ◆In Case of Problems ........................ 29 ◆A Final Note About Setup....................... 29 Main Menu ............................30 ◆Setup Items ..........................31 Main ..............................31 Advanced ............................
  • Page 6 ◆USB3.0 Port: USB3.0 ......................71 ◆Giga bit-Ethernet: LAN A, B ....................72 ◆Display Port Connector ......................73 ◆Serial Port Interface: SERIAL A, B ..................74 ◆GPIO Port: DIO ........................75 6. APPENDIX POST Codes ............................76 SERIAL I/O Address and Register Function ..................79 Baud Rate Settings ..........................

  • Page 7: Introduction

    & mSATA for storage and is fanless to ensure a totally spindleless design that simplifies maintenance. Embedded-type CPU have been adopted. The use of readily available parts ensures the ease of the use of the product. In addition, the use of Contec-customized BIOS allows support to be provided at the BIOS level.

  • Page 8: Features

    ◆Features - Contributing to reduction of running cost and promotion of energy efficiency. ® It adopts the low-power platform with Intel Core i5 & Celeron Processor that realizes lower power consumption while ensuring sufficient performance. - Design that meets the safety standard This product, as in our other products, is designed to comply with the safety standard of FCC, CE, and furthermore.

  • Page 9: Customer Support

    You can download updated driver software and differential files as well as sample programs available in several languages. ■Note! For product information Contact your retailer if you have any technical question about a CONTEC product or need its price, delivery time, or estimate information. Limited One-Year Warranty CONTEC products are warranted by CONTEC CO., LTD.

  • Page 10: Liability

    Liability The obligation of the warrantor is solely to repair or replace the product. In no event will the warrantor be liable for any incidental or consequential damages due to such defect or consequences that arise from inexperienced usage, misuse, or malfunction of this device. Safety precaution Understand the following definitions and precautions to use the product safely.
  • Page 11 To prevent corruption of files, always shutdown the OS before turning off this product. CONTEC reserves the right to refuse to service a product modified by the user. In the event of failure or abnormality (foul smells or excessive heat generation), unplug the power cord immediately and contact your retailer.
  • Page 12 FCC PART 15 Class A Notice NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in commercial environment.

  • Page 13: System Reference

    2. System Reference Specification Table 2.1. Functional specification< 1 / 2 > PT-S2000HX/HXC-DCxxxxxxx PT-S2000LX/LXC-DCxxxxxxx MODEL PT-S2000HX/HXC-DC2xxx PT-S2000HX/HXC-DC3xxx PT-S2000LX/LXC-DC2xxx PT-S2000LX/LXC-DC3xxx PROCESSOR Intel® Celeron 3955U Intel® Core i5-6300U Intel® Celeron 3955U Intel® Core i5-6300U CHIPSET Intel® SoC integrated MEMORY DDR4 2133/2400, 260-pin SO-DIMM x 2, Max. 32 GB (Non-ECC) GRAPHICS Intel®...
  • Page 14 PHYSICAL DIMENSIONS 372x303x84.7 316x256x85.4 UNIT: mm WEIGHT UNIT: Kg Table 2.1. Functional specification< 2 / 2 > MODEL PT-S2000HX/HXC-DCxxxxxxx PT-S2000LX/LXC-DCxxxxxxx LCD Panel 15" XGA 12" XGA Resolution Display 1024 x768.262K colors Luminance 450 nits 600 cd/m2 (Typ.) Touch Type Projected capacitive 89 ±3% Transparency (tavg) >...
  • Page 15 Table 2.2. Installation Environment Requirements PT-S2000HX/HXC-DCxxxxxxx PT-S2000LX/LXC-DCxxxxxxx MODEL PT-S2000HX/HXC-DC2x PT-S2000HX/HXC-DC3x PT-S2000LX/LXC-DC2x PT-S2000LX/LXC-DC3x xxxxx xxxxx xxxxx xxxxx PROCESSOR Intel® Celeron 3955U Intel® Core i5-6300U Intel® Celeron 3955U Intel® Core i5-6300U ENVIRONMENTAL OPERATING 0 ~ 50°C with 0.7m/s air flow (with Extended Temp. HDD/SSD/mSATA/RAM) TEMPERATURE 0 ~ 40°C with 0.7m/s air flow (with Standard Temp.

  • Page 16: Power Management Features

    Power Management Features Support both ACPI (Advanced Configuration and Power Interface). ACPI v2.0 compliant Hardware automatic wake-up Power Requirements Your system requires a clean, steady power source for reliable performance of the high frequency CPU on the product, the quality of the power supply is even more important. For the best performance makes sure your power supply provides a range of 12 V minimum to 24 V maximum DC power source.

  • Page 17: Physical Dimensions

    Physical dimensions PT-S2000HX/HXC Series Figure 2.1. PT-S2000HX/HXC Series Figure 2.2. PT-S2000HX/HXC Series Front Panel & Panel mount cut out size PT-S2000HX/HXC/LX/LXC Series User’s Manual...
  • Page 18 Figure 2.3. PT-S2000LX/LXC-DC Series Figure 2.4. PT-S2000LX/LXC-DC Series Front Panel & Panel mount cut out size PT-S2000HX/HXC/LX/LXC Series User’s Manual...

  • Page 19: Hardware Setup

    3. Hardware Setup Before Using the Product for the First Time Follow the next steps to set up this product. STEP1 By referring to the information in this chapter, install, connect and set this product. STEP2 Connect cables. Connect the cable of necessary external devices, such as keyboard and display, to this product using appropriate cables.

  • Page 20: Hardware Setup

    Hardware setup ・ Before you start, be sure that the power is turned off. ・ Remove only those screws that are explained. Do not move any other screw. ◆Panel mount & Attachment Fittings / PT-S2000HX/HXC CAUTION : The maximum thickness of the mounting bracket is 7mm Please place the mounting clip in the guide groove according to the direction as figure.

  • Page 21: Panel Mount & Attachment Fittings / Pt-S2000Lx/Lxc

    ◆Panel mount & Attachment Fittings / PT-S2000LX/LXC CAUTION : The maximum thickness of the mounting bracket is 7mm Please place the mounting clip in the guide groove according to the direction as figure. Recommended to secure the screws in the numerical order as figure.

  • Page 22: Fastening The Cable

    ◆Fastening the Cable This product comes with clamps for fixing cables. Fastening the LINEOUT, USB Cable (1) The system unit has a hole for attaching cable clamp to USB removal prevention fitting. Using a cable clamp for a cable with lock-less connector, such as the Audio cable and USB cable, prevents the connector from being unplugged.
  • Page 23 (2) To secure the screws from the sides of the hard drive. Please refer to the direction of the figure shown and place HDD driver into the frame. Figure 3.5. Secure the screws (3) Connect the SSD/HDD to the SATA cable and SATA power cable as figure. The connector on 2.5”...
  • Page 24 ◆Installing the Memory To install the modules, locate the memory slot on the board and perform the following steps: Remove the four screws lift from the back cover out of the PT-S2000HX/HXC/LX/LXC. locate the memory slot on the board. Figure 3.7. Remove back cover Hold the memory module and align the key of the module with that on the memory slot.
  • Page 25 NOTE To be fully compliant with all applicable DDR SDRAM memory specifications, the board should be populated with DIMMs that support the Serial Presence Detect (SPD) data structure. This allows the BIOS to read the SPD data and program the chipset to accurately configure memory settings for optimum performance.

  • Page 26: Installing The Mini Card

    ◆Installing the mini card To install the modules, locate the mini card slot on the PCB and perform the following steps: (1) Remove the four screws lift from the PC box out of the PT-S2000HX/HXC/LX/LXC. locate the mini card slot on the board Figure 3.9.

  • Page 27: Installing The M.2 Module

    ◆Installing the M.2 module To install the modules, locate the M.2 slot on the PCB and perform the following steps: (1) Remove the four screws lift from the PC box out of the PT-S2000HX/HXC/LX/LXC. locate the M.2 slot on the board Figure 3.11.

  • Page 28: Bios Setup

    4. BIOS setup Introduction This chapter discusses American Megatrends’ (AMI) Setup program built into the FLASH ROM BIOS. The Setup program allows users to modify the basic system configuration. This special information is then stored in FLASH ROM so that it retains the Setup information when the power is turned off. The rest of this chapter is intended to guide you through the process of configuring your system using Setup.

  • Page 29: Using Setup

    Using Setup In general, you use the arrow keys to highlight items, press <Enter> to select, use the Page Up and Page Down keys to change entries, press <F1> for help and press <Esc> to quit. The following table provides more detail about how to navigate in the Setup program using the keyboard.

  • Page 30: Main Menu

    Main Menu When the setup program (Aptio Startup Utility) is started, the main menu will be displayed. Navigate through the various tabs by pressing the right and left arrow keys. Figure 4.1. Main Menu PT-S2000HX/HXC/LX/LXC Series User’s Manual...

  • Page 31: Setup Items

    ◆Setup Items The selectable tabs are as follows. - Main View the basic system structure, and configure the language settings and the date and time settings. - Advanced Specify the detailed functions that can be set on the system used. - Chipset Specify the detailed functions that can be set on the system used.
  • Page 32 Field Name Build Date Default Value Display build date of the BIOS Comment This field is not selectable. There is no help text associated with it. Field Name ME FW Version Default Value ME Firmware Version Comment This field is not selectable. There is no help text associated with it. Field Name Processor Information Default Value...
  • Page 33 Field Name System Time Default Value [hh :mm :ss] hh : 0-23 Possible Value mm : 0-59 ss : 0-59 Help Set the Time. Use Tab to switch between Time elements PT-S2000HX/HXC/LX/LXC Series User’s Manual...

  • Page 34: Advanced

    Advanced Specify the detailed system functions. The following items are available. Figure 4.2. Advanced Menu Table 4.3. Indication item of the advanced menu Field Name CPU Configuration Help CPU Configuration Parameters. Comment Press Enter when selected to go into the associated Sub-Menu. Field Name Trusted Computing Help...
  • Page 35 Field Name SMART Settings Help System SMART Settings Comment Press Enter when selected to go into the associated Sub-Menu. Field Name Super IO Configuration Help System Super IO Chip Parameters. Comment Press Enter when selected to go into the associated Sub-Menu. Field Name Hardware Monitor Help...

  • Page 36: Cpu Configuration

    ◆CPU Configuration Configure the operation settings for CPU. Figure 4.3. CPU Configuration Table 4.4. Indication item of the advanced menu Field Name Type Default [Intel CPU Brand String] Value Comment This field is not selectable. There is no help text associated with it. Field Name L4 Cache Default...
  • Page 37 Field Name Default VMX Supported or Not Value Comment This field is not selectable. There is no help text associated with it. Field Name SMX/TXT Default SMX/TXT Supported or Not Value Comment This field is not selectable. There is no help text associated with it. Field Name Hardware Prefetcher Default...
  • Page 38 Enabled Possible Value Disabled Enables utilization of additional hardware capabilities provided by Intel(R) Help Trusted Execution Technology.Changes require a full power cycle to take effect. PT-S2000HX/HXC/LX/LXC Series User’s Manual...

  • Page 39: Acpi Settings

    ◆ACPI Settings Configure the settings for ACPI power management. Figure 4.4. ACPI Settings Table 4.5. Indication item of the advanced menu Field Name Enable ACPI Auto Configuration Default [Disabled] Value Enabled Possible Value Disabled Help Enables or Disables BIOS ACPI Auto Configuration Field Name Enable Hibernation Default [Enabled]...
  • Page 40 Field Name ACPI Sleep State Default [S3 (Suspend to RAM)] Value Suspend Disabled Possible Value S3 (Suspend to RAM) Select the highest ACPI sleep state the system will enter when the Help SUSPEND button is pressed. PT-S2000HX/HXC/LX/LXC Series User’s Manual...

  • Page 41: Smart Setting

    ◆SMART Setting Configure the operation settings for SMART Self-Test. Figure 4.5. SMART Setting Table 4.6. SMART Setting Configuration Field Name SMART Self-Test Default Value [Disabled] Enabled Possible Value Disabled Help Run SMART Self-Test on all HDDs during POST PT-S2000HX/HXC/LX/LXC Series User’s Manual...

  • Page 42: Super Io Configuration

    ◆Super IO Configuration Configure the operation settings for Super IO. Figure 4.6 Super IO Configuration Table 4.7. Super IO Configuration Field Name Serial Port 1 Configuration Help Set Parameters of Port 1 (COM A) Comment Press Enter when selected to go into the associated Sub-Menu. Field Name Serial Port 2 Configuration Help Set Parameters of Port 2 (COM B)

  • Page 43: Serial Port 1 (Com A)

    ◆Serial Port 1 (COM A) Figure 4.7. Serial Port 1 configuration Table 4.8. Serial Port 1 Configuration Field Name Serial Port Default Value [Enabled] Enabled Possible Value Disabled Help Enable or Disable Serial Port (COM A) Field Name Device Settings Default Value Device Super IO COM A Address and IRQ.

  • Page 44: Serial Port 2 (Com B)

    ◆Serial Port 2 (COM B) Figure 4.8. Serial Port 2 Configuration Table 4.9. Serial Port 2 Configuration Field Name Serial Port Default Value [Enabled] Enabled Possible Value Disabled Help Enable or Disable Serial Port (COM B) Field Name Device Settings Default Value Device Super IO COM2 Address and IRQ.
  • Page 45 Field Name Mode Configuration Default Value [3T/5R RS232] 1T/1R RS422 3T/5R RS232 1T/1R RS485 TX ENABLE Low Active Possible Value 1T/1R RS422 with termination resistor 1T/1R RS485 with termination resistor TX ENABLE Low Active Disabled Help Configure serial port as RS232/RS422/RS485 PT-S2000HX/HXC/LX/LXC Series User’s Manual...

  • Page 46: H/W Monitor

    ◆H/W Monitor View hardware monitor information such as the CPU temperature. Figure 4.9. H/W Monitor (PC Health Status) PT-S2000HX/HXC/LX/LXC Series User’s Manual...

  • Page 47: S5 Rtc Wake Settings

    ◆S5 RTC Wake settings Configure the SATA controller settings. Figure 4.10. Wake setting Configuration Table 4.10. Wake setting Configuration Field Name Wake system from S5 Default Value [Disabled] Disabled Possible Value Fixed Time Enabler or disable System wake on alarm event, Select FixedTime, Help system will wake on the hr::min::sec specified.
  • Page 48 Field Name Wake up minute (Show when Wake system from S5 set to Fixed Time) Default Value Possible Value 0~59 Help 0-59 PT-S2000HX/HXC/LX/LXC Series User’s Manual...

  • Page 49: Network Stack Configuration

    ◆Network Stack Configuration Configure settings associated with the CSM (Compatibility Support Module), such as Option ROM execution. Figure 4.11. Network Stack Configuration Table 4.11. Network Stack Configuration Field Name Network stack Default Value [Disabled] Disabled (Restore non-Windows 8 Default) Possible Value Enabled Help Enable/Disable UEFI Network stack...
  • Page 50 Enable Ipv6 PXE Boot Support. If disabled IPV6 PXE boot option will Help not be created. PT-S2000HX/HXC/LX/LXC Series User’s Manual...

  • Page 51: Chipset

    Chipset Specify the detailed chipset functions. Figure 4.12. Chipset Table 4.12. Chipset Configuration Field Name System Agent (SA) Configuration Help System Agent (SA) Parameters Comment Press Enter when selected to go into the associated Sub-Menu. Field Name PCH-IO Configuration Help PCH Parameters Comment Press Enter when selected to go into the associated Sub-Menu.

  • Page 52: System Agent (Sa) Configuration

    ◆System Agent (SA) Configuration Configure the operation settings for system agent (SA). Figure 4.13. System agent (SA) Table 4.13. System agent (SA) Field Name Memory Configuration Help Memory Configuration Parameters Comment Press Enter when selected to go into the associated Sub-Menu. Field Name Graphics Configuration Default Value Graphics Configuration...

  • Page 53: Memory Configuration

    ◆Memory Configuration Configure how memory will be used when using the graphic function. Leave these settings as configured before shipment. Figure 4.14. Memory Configuration Table 4.14. Memory Configuration Field Name Memory Frequency Help Memory speed Comment This field is not selectable. There is no help text associated with it. Field Name DIMM#[1:2] Help...

  • Page 54: Graphic Configuration

    ◆Graphic Configuration Configure the graphic setting. Figure 4.15. Graphic configuration Table 4.15. Graphic Control Field Name DVMT Pre-Allocated Default Value [32M] 32M / 64M / 4M/ 8M/ 12M/ 16M/ 20M/ 24M/ 28M/ (32M/F7)/ Possible Value 36M/ 40M/ 44M/ 48M/ 52M/ 56M/ 60M Select DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size Help used by the Internal Graphics Device.

  • Page 55: Pch-Io Configuration

    ◆PCH-IO Configuration Configure the South Bridge settings. Figure 4.16. PCH-IO Configuration Table 4.16. PCH-IO Configuration Field Name HD Audio Configuration Help HD Audio Subsystem Configuration Settings Comment Press Enter when selected to go into the associated Sub-Menu. Field Name DeepSx Power Policies Default Value [Disabled] Enabled in S4-S5...

  • Page 56: Azalia Hd Audio Configuration

    ◆Azalia HD Audio Configuration Configure the Azalia HD Audio settings. Figure 4.17. Azalia HD Audio Configuration Table 4.17. Azalia HD Audio Configuration Field Name HD Audio Default Value [Auto] Possible Value Auto / Enable / Disable Control Detection of HD-Audio device. Disabled = HDA will be unconditionally disabled Help Enable = HDA will be unconditionally enabled...

  • Page 57: Security

    Security Configure the security of the system settings. Figure 4.18. Security Table 4.18. Security Configuration Field Name Administrator Password Help Set Administrator Password Field Name User Password Help Set User Password PT-S2000HX/HXC/LX/LXC Series User’s Manual...
  • Page 58 Field Name HDD Security drive Help HDD Security Configuration for selected drive Comment Press Enter when selected to go into the associated Sub-Menu Field Name Secure Boot Help Customizable Secure Boot settings Comment Press Enter when selected to go into the associated Sub-Menu Field Name Secure Flash Update Help...

  • Page 59: Hdd Security

    ◆HDD Security Configure the security of the system settings. Figure 4.19. HDD Security Table 4.19. HDD Security Configuration Field Name Set User Password Set HDD User Password. *** Advisable to Power Cycle System after Setting Hard Disk Passwords ***.Discard or Save changes option in Help setup does not have any impact on HDD when password is set or removed.

  • Page 60: Secure Boot

    ◆Secure Boot Configure the security of the system settings. Figure 4.20. Secure boot Table 4.20. Secure boot Configuration Field Name Secure Boot Enable Default Value [Disabled] Enabled Possible Value Disabled Secure Boot activated when Platform Key(PK) is enrolled, System mode is Help User/Deployed, and CSM function is disabled Field Name...
  • Page 61 Field Name Restore Factory Keys Force System to User Mode. Configure NVRAM to contain OEM-defined Help factory default Secure Boot keys Field Name Reset to Setup Mode Help Delete NVRAM content of all UEFI Secure Boot key databases PT-S2000HX/HXC/LX/LXC Series User’s Manual...

  • Page 62: Secure Flash Update

    ◆Secure Flash Update Figure 4.21. Path of ROM Image Table 4.21. Path of ROM Image Field Name Path for ROM Image Help Enter the path to the Secure flash option PT-S2000HX/HXC/LX/LXC Series User’s Manual...

  • Page 63: Boot Configuration

    Boot Configuration Configure the settings boot devices and other devices. Figure 4.22. Boot Configuration Table 4.22. Boot Configuration Field Name Setup Prompt Timeout Default Value 1 Possible Value 1~65535 Number of seconds to wait for setup activation key. 65535(0xFFFF) Help means indefinite waiting.
  • Page 64 Field Name Bootup NumLock State Default Value [On] Possible Value Help Select the keyboard Num lock state Field Name Boot Mode Select Default Value [UEFI] LEGACY (Support Skylake series for Win7) Possible Value UEFI Help Select boot mode LEGACY/UEFI Field Name Boot Option #1 Default Value [USB Floppy]...
  • Page 65 Field Name Boot Option #6 Default Value [USB Lan] Hard Disk, USB Hard Disk, USB CD/DVD, USB Key, USB Floppy, Possible Value USB Lan, Network Help Sets the system boot order Field Name Boot Option #7 Default Value [Network] Hard Disk, USB Hard Disk, USB CD/DVD, USB Key, USB Floppy, Possible Value USB Lan, Network Help...

  • Page 66: List Boot Device Type

    ◆List Boot Device Type Configure the list boot devices. Figure 4.23. Boot Configuration Table 4.23. Boot Configuration Field Name Boot Option #1 Default Value /Blank/ Help Boot Device Name 1 of this type Sets the system boot order Comment Field Name Boot Option #2 Default Value /Blank/...

  • Page 67: Save & Exit

    Save & Exit Load/save setup items and exit the setup menu. Figure 4.24 Save & Exit menu Table 4.24. Save & Exit menu Field Name Discard Changes and Exit Help Exit system setup with without saving any changes Field Name Save Changes and Reset Help Reset the system after saving the changes.

  • Page 68: Each Component Function

    5. Each component function Component name Figure 5.1. Component Name Table 5.1. Component Name Pos. Description Function Power Connector DC power input connector Audio Jack Ø 3.5 Audio JACK Display port Display port connector HDMI HDMI connector LAN Port A Ethernet 1000BASE-T/100BASE-TX/10BASE-T RJ-45 connector LAN Port B Ethernet 1000BASE-T/100BASE-TX/10BASE-T RJ-45 connector...

  • Page 69: Component Function

    Component Function ◆LED: POWER, ACCESS There are 3 LED in front of this product. Table 5.2. Display Contents of LED LED Name State Display contents Indicates that this product is switched off. Power LED ON (Green) Indicates that this product is switched on. ON (Blue) Access LED ON (Red)

  • Page 70: Power Sw

    ◆POWER SW POWER SW is provided. ◆LINE OUT Interface: LINE OUT The product is equipped with a connector for line output. As such, headphones or an amplified speaker can be connected. ◆HDMI Interface: Table 5.4. HDMI Connector Connector type HDMI type A receptacle (female) Pin No.

  • Page 71: Usb3.0 Port: Usb3.0

    ◆USB3.0 Port: USB3.0 This product is equipped with 1 channel for USB 3.0 TYPE-A interface. Table 5.5. USB3.0 Connector Connector type USB 3.0 Type A Pin No. Signal name Pin No. Signal name USB_VCC SSRX- DATA- SSRX+ DATA+ USB_GND USB_GND SSTX- SSTX+ PT-S2000HX/HXC/LX/LXC Series User’s Manual...

  • Page 72: Giga Bit-Ethernet: Lan A, B

    ◆Giga bit-Ethernet: LAN A, B This product is equipped with 2 ports for giga bit. Table 5.6. Giga bit-Ethernet Connector LED Name Color State Condition LAN link is not established Link LAN link is established Green Blinking LAN activity occurring 10 Mb/s data rate Speed Green...

  • Page 73: Display Port Connector

    ◆Display Port Connector Table 5.8. Display Port Connector Connector type DisplayPort plug connector Pin No. Signal name Pin No. Signal name Lane 0 (+) Ground Ground Lane 3 (-) Lane 0 (-) (Ground) Lane 1 (+) (Ground) Ground Auxiliary channel (+) Lane 1 (-) Ground Lane 2 (+)

  • Page 74: Serial Port Interface: Serial A, B

    ◆Serial Port Interface: SERIAL A, B The product has 2 channels of RS232C compliant serial ports supporting up to a baud rate of 115,200bps with a 16-byte transmission-dedicated data buffer and a 16-byte reception-dedicated data buffer. You can use “Chapter 4 BIOS Setup” to configure an I/O address, interrupt and unused state for each of the ports independently.

  • Page 75: Gpio Port: Dio

    ◆GPIO Port: DIO The product is equipped with an interface to which you can connect a remote switch and a GPIO device. GPIO is not isolated. Table 5.10 Digital I/O connector Connector type 9-pin D-SUB (MALE) No.4-40UNC Inch screw threads Pin No.

  • Page 76: Appendix

    6. Appendix POST Codes Table 6.1. POST Codes < 1 / 3 > POST Description (hex) < Security (SEC) phase > Power ON. The detection of the reset kind (Hard/Soft) Initialize the microcode load previous AP Initialize the microcode load previous North Bridge Initialize the microcode load previous South Bridge Initialize the microcode load previous OEM Microcode load...
  • Page 77 Table 6.1. POST Codes < 2 / 3 > POST Description (hex) South Bridge runtime services installation CPU DXE installation start 64h - 67h CPU DXE installation start (Specific CPU module) PCI host bridge installation North Bridge DXE initialization starts North Bridge DXE SMM initialization starts 6Bh - 6Fh North Bridge DXE initialization (Specific North Bridge module)
  • Page 78 Table 6.1. POST code < 3 / 3 > POST Description (hex) Legacy option ROM initialization System reset USB hotplug PCI bus hot plug NVRAM cleanup Configuration reset (Reset the NVRAM settings) B8h - BFh For future AMI codes reserved C0h - CFh OEM BDS initialization code ACPI/ASL Checkpoints...

  • Page 79: Serial I/O Address And Register Function

    SERIAL I/O Address and Register Function The following table lists the I/O addresses in case of SERIAL A. Table 6.2. I/O Port Addresses I/O address DLAB Read/Write Register 03F8H Transmitter holding register Receive buffer register Divisor latch register (LSB) 03F9H Divisor latch register (MSB) Interrupt enable register 03FAH...
  • Page 80 Table 6.3. Function of Each Register < 1 / 4 > I/O address Description 03F8H THR: Transmitter Holding Register [DLAB=0] Register dedicated to write transmitted data to 03F8H RBR: Reciever Buffer Register [DLAB=O] Register dedicated to read received data from 03F8H DLL: Divisor Latch (LSB) [DLAB=1] Baud rate setting register (LSB)
  • Page 81 Table 6.3. Function of Each Register < 2 / 4 > I/O address Description 03FAH IIR : Interrupt Identification Register 03FBH LCR : Line Contror Regester PT-S2000HX/HXC/LX/LXC Series User’s Manual...
  • Page 82 Table 6.3. Function of Each Register < 3 / 4 > I/O address Description 03FCH MCR: Modem Control Register 03FDH LSR: Line Status Regester PT-S2000HX/HXC/LX/LXC Series User’s Manual...
  • Page 83 Table 6.3. Function of Each Register < 4 / 4 > I/O address Description 03FEH MSR : Modem Status Register 03FFH SCR : Scratchpad Register This is an 8-bit, readable/writable register which is available to the user to allow data to be saved temporarily. PT-S2000HX/HXC/LX/LXC Series User’s Manual...

  • Page 84: Baud Rate Settings

    Baud Rate Settings A baud rate is set by software by dividing the clock input (1.8432MHz). The baud rate in terms of hardware can be set to a maximum of 115,200 bps for SERIAL A, B. The baud rates available in practice depend on the operating environment (cable, software, etc.).

  • Page 85: S2000Hx/Hxc/Lx/Lxc Gpio Programming Guide

    PT-S2000HX/HXC/LX/LXC GPIO Programming guide ◆PT-S2000HX/HXC/LX/LXC GPIO v3.02 MiAPI GPIO ============================================ Options: -h, -?, Help information. Show current product name and BIOS version. -get n Get status PIN n -set n aa bb Set status PIN n with dir and level dir aa : 0 -->...
  • Page 86 4. show the all status of PINs. BXS2000_GPIO -all Result: PIN 1234-5678 ==== ==== In(1)/Out(0): 0101 0101 Level : 0111 0111 PS. It will display 'E' when the specific pin has error, 5. Set PIN 5 as input pin and pull low. But it should ignore the level setting because its input source is high in this case.
  • Page 87 Purpose: Make 4 input-output pairs to cross-verify the GPIO functions. Procedure: 1. Use 4 jumpers or wires to connect the following pin cobination. 1 - 6, 2 - 3, 4 - 5, 7- 8 =========================== | 1 2 -- 3 4 -- 5 | as DB9 connector shown.
  • Page 88 PIN 1234-5678 ==== ==== In(1)/Out(0): 0010 1101 Level : 1111 1111 Compare : 1111 1111 Level comparison is identical. 3. Set PINs 3, 5, 6, 8 as Output; PINs 1, 2, 4, 7 as input. Case C: Set all Output level to Low; It is expected that other input PINs should be pulled low, and eventually all PINs levels should be 0.
  • Page 89 Compare : 1111 1111 Level comparison is identical. PS. These test cases must meet the requirement in step 1. Otherwise the comparsion will show "mismatch", and return errorlevel 4. PT-S2000HX/HXC/LX/LXC Series User’s Manual...

  • Page 90: Watchdog Timer Application Guide

    Watchdog timer application guide ======================================== The MiAPI provides some APIs for watchdog feature to act as user-application monitoring service. These APIs are as following: MiAPI_Watchdog_SetConfig : Set watchdog timer timeout value. MiAPI_Watchdog_GetRange : Get current timeout value and its range. MiAPI_Watchdog_Start : Activate the watchdog timer countdown.

  • Page 91: Design Note

    Remarks User can query current watchdog timer counter by MiAPI Watchdog GetRange function. It can optionally place in either main thread or monitoring thread as user likes. ◆Design Note ======================================= 1. Behavior after watchdog reset When watchdog timer expires, it trigger a reset signal to system. It is up to user how motherboard behaviors after it reset.
  • Page 92 CSampleService::OnStart, which is executed when the service starts. And it calls CThreadPool::QueueUserWorkItem to queue the monitoring service function (CSampleService::ServiceWorkerThread) for execution in a worker thread. void CSampleService::OnStart(DWORD dwArgc, LPWSTR *lpszArgv) // -- Start the MiAPI library MiAPI_Start(); //-- Set up WDT 30 seconds timeout and reboot MiAPI_Watchdog_SetConfig(30, true);...
  • Page 93 performs the monitoring function of the service such as the communication with client applications through a named pipe. In order that the thread finishes gracefully when the service is about to stop, it should periodically check the m_fStopping varaible and refresh the WDT timer. When the function detects that the service is stopping, it cleans up the work and signal the m_hStoppedEvent event object.

  • Page 94: Miapi Watchdog Setconfig Description

    ◆MiAPI Watchdog SetConfig Description Set watchdog timer with specified timeout value and define the action to reboot or trigger a WD_TIME pin when expired. Int MiAPI_Watchdog_SetConfig (DWORD Timeout, BOOL Reboot) Parameters Timeout [in] Specifies a value in seconds for the watchdog timeout. Reboot [in] True to reboot system when expired;...

  • Page 95: Miapi Watchdog Start Description

    MiAPI_WDT_GET_FAIL (0x21) Fail Remarks This function provides an indicator to show time range and the current remained time before watchdog expires. They are read-only, and will not alter watchdog’s countdown. ◆MiAPI Watchdog Start Description Start the watchdog timer. int MiAPI_Watchdog_Start(void) Parameters None Return Value...

  • Page 96: Miapi Watchdog Refresh Description

    ◆MiAPI Watchdog Refresh Description Reset the watchdog timer to the timeout value set by MiAPI_Watchdog_SetConfig. It is always inserted in application main loop to prevent watchdog expires. int MiAPI_Watchdog_Refresh (void) Parameters None Return Value MiAPI_OK (0x00) Success MiAPI_WDT_SET_FAIL (0x22) Fail Remarks It is better for users to set a longer 1.5~2 times timeout than user’s service loop.
  • Page 97 Battery Battery Specification This product uses the following battery. - Type : Lithium primary battery - Model : CR2032 - Maker : JHT - Nominal voltage : 3V - Nominal capacity : 220mAh - Lithium content : 1g or less Removing the battery Remove the battery according to the following figure.

  • Page 98: List Of Optional Product

    Precautions when using products other than our options If a product other than our option is used, the normal operation may be impaired or the functions may be limited. *Visit Contec website regarding information on the optional products. PT-S2000HX/HXC/LX/LXC Series User’s Manual...
  • Page 99 PT-S2000HX/HXC/LX/LXC Series User’s Manual CONTEC CO.,LTD November 2019 Edition 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan Japanese http://www.contec.com/jp English http://www.contec.com/ Chinese http://www.contec.com/cn All rights reserved. This product and this document are protected by copyright law. Unauthorized copying, duplication, reproduction, and tampering are prohibited.
