Supported Os - Contec IPC Series User Manual

- Safety design required for embedded applications
Retention of CMOS data by EEPROM allows the system to start up even when the battery has run out.
For Windows Embedded Standard installed model or Windows 10 IoT Enterprise LTSB 2016 installed
model, it is possible to use the Write Filter*2 function of OS. It is designed for safety required for
embedding purpose, for example, prohibiting unwanted writing to the CFast card with Write Filter
function will relieve the concern about the writing limits to the CFast card and prevent an unintentional
system alteration.
*2 Windows® Embedded Standard contains EWF(Enhanced Write Filter) function, and Windows 10 IoT Enterprise LTSB 2016 contains
UWF(Unified Write Filter) function. They redirect writing data into such as RAM, which stops writing in the actual disk and data can
be protected.
- A wide range of power supplies (10.8 - 31.2VDC) supported
As the product supports a wide range of power (10.8 - 31.2VDC), it can be used in a variety of power
environments. The separately available AC adapter adds support for 100VAC power.

Supported OS

- Windows Embedded Standard 7 RUNTIME P (Japanese, English, Chinese, Korean), 32bit
- Windows 10 IoT Enterprise LTSB 2016 (Japanese, English, Chinese, Korean), 64bit
PT-956SxX Series User's manual
1. Introduction
3
