1. Introduction

Features

- Multilingual OS is adopted for globalization support
Windows Embedded Standard 7 RUNTIME P and Windows 10 IoT Enterprise LTSB that support
multiple languages of Japanese/English/Chinese/Korean are adopted as the OS installation model. As the
language on the screen can be switched, this feature is ideal for such as manufacturing sites where
multilingualization is inevitable.
- Contributing to reduction of running cost and promotion of energy efficiency
With the low power consumption platform Intel® Atom
power consumption while ensuring adequate performance.
- Fanless design that reduces maintenance work
This product's spindleless design eliminates the heat dissipating slit and CPU fan and adopts CFast card
for the storage. It is free from dusts and foreign objects, and the use the parts that degrades over the
years is avoided in most case, resulting in drastic alleviation of the maintenance burden.
- Remote power management function to reduce operation tasks
It supports system start-up externally via network (Wake On LAN) and modem (Power On by Ring). It
encourages significant labor saving in operation.
- Adopting a 5-wire resistive film touch-screen holds high durability
It has a 5-wire resistive film touch-screen that maintains high durability. The operating life is long-lasting
of 36 million times.
*1 with Load 300g, Speed twice/second, by machine keying
- High definition supported DVI external display output
This product has the up to 1920 x 1080 pixels DVI external display output as standard feature. A stand-
alone two-display application which, for example, displays the screen on a big LCD TV separately from
the main LCD, can be built. Also, with the accompanying analog RGB (15 pin HD-SUB) conversion
adapter, connecting to an analog RGB display is supported.
- Major types of peripherals are supported with rich interfaces including the two CFast card slots
It has a variety of extended interface such as DVI-I x1, 1000BASE-T x 2, USB3.0 x 1, USB2.0 x 3, serial
(RS-232C) x 2.
It has 2 CFast card slots that can use for OS and data. They are very useful because you can use one slot
for system start-up and the other for maintenance, system log, or taking away the collected data.
- CFast retention fitting and cable tie provided to avoid trouble caused by disconnected cable
This product stays trouble-free, being equipped with CFast card retention metal and USB removal
prevention fitting and cable tie for connectors with no locking mechanism, such as USB cable, and with
hardware to properly mount and avoid falling out of CFast card.
2
TM
processor E3845, this product achieves low
PT-956SxX Series User's manual
