Distances between this product and its vicinity
50mm
or
more
Installation panel
Figure 3.12. Distances between this product and its vicinity
CAUTION
-
Wall temperatures should be within the guaranteed operating temperature range of the product.
-
Adjust the air flow so as not to allow waste heat from the product to accumulate around the product.
-
Do not install this product into the fully-sealed space except the case in which the internal
temperature is adjustable by equipment such as air conditioner. Troubles such as operational
malfunctions could be occurred by the temperature increase caused by long-term usage.
PT-956SxX Series User's manual
50mm
or more
50mm
or
more
50mm
or more
3. Hardware Setup
50mm
or
more
23
