Attaching the FG

(1) Use screws to attach the FG.
Figure 3.2. Attaching the FG
CAUTION
The FG pin of this product is connected to the GND signal of the DC power connector (DC-IN).
Note that the connection cannot be cut off.
Screw holes may be damaged if screws are tightened with a torque greater than the specified torque.
The specified tightening torque is 5 - 6kgf⋅cm.
