6. Appendix
Differences between the PT-956SxX Series and
the PT-955xX Series
Model
CPU Intel® Atom™ Processor E3845 1.91GHz
Chipset None
Memory -DC7xxxxx : 4GB (204pin SO-DIMM x 1),
-DC8xxxxx : 8GB (204pin SO-DIMM x 1),
Graphic Controller Intel® HD Graphics (Built inCPU)
External DVI 640 x 480, 800 x 600, 1,024 x 768, 1,152 x 864,
display 1,280 x 600, 1,280 x 720, 1,280 x 768,
output 1,280 x 800, 1,280 x 960, 1,280 x 1,024,
1,360 x 768, 1,366 x 768, 1,400 x 1,050,
1,440 x 900, 1,600 x 900, 1,680 x 1,050,
1,920 x 1,080 (1,6770,000 colors)
Analog 640 x 480, 800 x 600, 1,024 x 768, 1,152 x 864,
RGB 1,280 x 600, 1,280 x 720, 1,280 x 768,
1,280 x 800, 1,280 x 960, 1,280 x 1,024,
1,360 x 768, 1,366 x 768, 1,400 x 1,050,
1,440 x 900, 1,600 x 900, 1,680 x 1,050,
1,920 x 1,080, 1,920 x 1,200 (1,6770,000 colors)
LAN Intel I210IT Controller
1000BASE-T/100BASE-TX/10BASE-T 2 port
(Wake On LAN support)
USB USB3.0 compliant 1port
(TYPE-A connector x 1)
USB2.0 compliant 3port
(TYPE-A connector x 3)
Real time clock Lithium backup battery life: 10 years or more,
The real-time clock is accurate within ±3
minutes (at 25°C) per month (CPU built-in
RTC)
Power Management Power management setup via BIOS, Power On
by Ring/Wake On LAN, Supports PC98/PC99
ACPI Power management
Interface Audio LINE OUT: 3.5φStereo mini jack,
Full-scale output level 1.4Vrms(Typ.)
MIC IN: 3.5φStereo mini jack,
Full-scale input level 1.4Vrms(Typ.)
Power Power 12VDC:
supply supply 1.7A(Typ.) 3.6A(Max.)
connector
24VDC:
1.0A(Typ.) 1.9A(Max.)
External CFast card slot :
device +3.3VDC 1A(500mA per slot),
power
USB3.0 I/F: +5V : 0.9A(900mA per port)
supply
USB2.0 I/F: +5V : 1.5A(500mA per port)
capacity
Weight About 3.4kg
(without mounting
bracket)
About 3.5kg
(with mounting
bracket)
84
PT-956SLX PT-956SHX
PC3-10600 DDR3L 1333 ECC
PC3-10600 DDR3L 1333 ECC
12VDC:
1.7A(Typ.) 3.5A(Max.)
24VDC:
1.0A(Typ.) 1.9A(Max.)
About 4.4kg
(without mounting
bracket)
About 4.5kg
(with mounting
bracket)
PT-955SLX
Intel® Atom™ Processor N2600 1.6GHz
Intel® NM10
2GB (204pin SO-DIMM x 1),
PC3-8500 DDR3 SDRAM
Intel® GMA3650 (Built inCPU),
Multi-monitor function supported *1
640 x 480, 800 x 600, 1,024 x 768, 1,280 x 768,
1,280 x 1,024, 1,360 x 768, 1,400 x 1,050,
1,600 x 900, 1,600 x 1,200, 1,920 x 1,080,
1,920 x 1,200 (16,770,000 colors)
640 x 480, 800 x 600, 1,024 x 768, 1,280 x 768,
1,280 x 1,024, 1,360 x 768, 1,400 x 1,050,
1,600 x 900, 1,600 x 1,200, 1,920 x 1,080,
1,920 x 1,200 (16,770,000 colors)
Intel 82573L Controller
1000BASE-T/100BASE-TX/10BASE-T 2 port
(Wake On LAN support)
USB 2.0 compliant 4 port
(TYPE-A connector x 4)
Lithium backup battery life: 10 years or more,
The real-time clock is accurate within ±3
minutes (at 25°C) per month
Power management setup via BIOS, Power On
by Ring/Wake On LAN, Supports ACPI Power
management
LINE OUT: φ3.5 Stereo mini jack,
Full-scale output level 1.2Vrms(Typ.).
MIC IN: φ3.5 Stereo mini jack,
Full-scale input level 1.5Vrms(Typ.)
12VDC: 12VDC:
2.3A(Typ.) 3.2A(Max.) 1.7A(Typ.) 3.0A(Max.)
24VDC: 24VDC:
1.2A(Typ.) 2.0A(Max.) 1.1A(Typ.) 1.6A(Max.)
CFast card slot:
+3.3VDC 1A(500mA per slot),
USB2.0 I/F : +5VDC 2A(500mA per slot)
About 3.5kg About 4.7kg (without
(without mounting mounting bracket)
bracket) About 4.8kg (with
About 3.6kg mounting bracket)
(with mounting
bracket)
PT-956SxX Series User's manual
PT-955SHX
