H/W Monitor

View hardware monitor information such as the CPU temperature.
Advanced
Pc Health Status
System temperature
CPU temperature
VCORE
+1.8V
+5 V
+12 V
+3.3 VSB
+3.3 VCC
VBAT
Figure 5.6. H/W Monitor (Actual Display May Vary.)
PT-956SxX Series User's manual
Aptio Setup Utility - Copyright (C) 20xx American Megatrends, Inc.
: +35 C
: +42 C
: +0.888 V
: +1.760 V
: +5.024 V
: +12.032 V
: +3.312 V
: +3.296 V
: +3.216 V
Version x.xx.xxxx. Copyright (C) 20xx American Megatrends, Inc.
5. BIOS Setup
→←:Select Screen
↑↓:Select Item
Enter:Select
+/-:Change Opt.
F1:General Help
F2:Previous Values
F3: Load Defaults for Win7
F4:Save & Exit
F5:Load Defaults for Win10
ESC:Exit
