Contec IPC Series User Manual

Hide thumbs Also See for IPC Series:
Table of Contents

Advertisement

Quick Links

See also: User Manual , Manual
IPC Series
PANECON-PC
IPC-PT/H630X(PCI) Series,
IPC-PT/L630S(PCI) Series
User's Manual
CONTEC CO.,LTD.

Advertisement

Table of Contents
loading

Related Manuals for Contec IPC Series

Summary of Contents for Contec IPC Series

  • Page 1 IPC Series PANECON-PC IPC-PT/H630X(PCI) Series, IPC-PT/L630S(PCI) Series User’s Manual CONTEC CO.,LTD.

  • Page 2: Trademarks

    Copyright 2003 CONTEC CO., LTD. ALL RIGHTS RESERVED No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this document.

  • Page 3: Table Of Contents

    Table of Contents Copyright ................. i Trademarks ..............i Table of Contents ............ii Introduction............1 Features ................2 Compatible Operating Systems ........2 Limited One-Year Warranty........3 How to Obtain Service..........3 Liability................3 Handling Precautions..........4 Overview............9 Specifications ..............9 System Configuration ............13 External Dimensions .............14 Hardware Setup ...........
  • Page 4 I/O Device Configuration Window ......38 Security Window ............40 Power Window............41 PC-Health Window ........... 42 Boot Window ............. 43 Exit Window .............. 44 Each Component Function ......45 Component Identification ......... 45 Line in Interface ............48 Line out Interface ............. 48 MIC input Interface ..........
  • Page 5 User’s Manual...

  • Page 6: Introduction

    1. Introduction 1. Introduction The IPC-PT/x630x(PCI) is a series of IBM PC/AT compatible, panel computers with touch panel designed for industrial use. It incorporates the 800 MHz version of the Low Voltage Intel(R) Pentium(R) III Processor Module (LPM), capable of running with a completely naturally cooled (fanless) structure.

  • Page 7: Features

    - Long, reliable supply (The CPU and chip set are embedded versions.) - Adoption of BIOS (Phoenix Technologies, Ltd.) customized by CONTEC to support the BIOS level - Other than the conforming PC I/F, equipped with the PCMCIA (for CardBus), Audio (AC97 conforming), 100BASE-TX and...

  • Page 8: Limited One-Year Warranty

    1. Introduction Limited One-Year Warranty CONTEC Products are warranted by CONTEC CO., LTD. to be free from defects in material and workmanship for up to one year from the date of purchase by the original purchaser. Repair will be free of charge only when this device is returned...

  • Page 9: Handling Precautions

    1. Introduction Handling Precautions Take the following precautions when handling this product. WARNING - Always check that the power supply is turned off before connecting or disconnecting power cables. - Do not modify the product. - Always turn off the power before inserting or removing circuit boards or cables.
  • Page 10 - CONTEC reserves the right to refuse to service a product modified by the user. - In the event of failure or abnormality (foul smells or excessive...
  • Page 11 1. Introduction - Component Life: 1. Power supply--- Estimated life is about 10 years based on continual operation at 40°C (horizontal installation). However, (higher) operating temperatures will result in shorter life. 2. Battery--- The internal calendar clock and CMOS RAM are backed by a Lithium primary battery.
  • Page 12 1. Introduction FCC PART 15 Class A Notice NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in commercial environment.
  • Page 13 1. Introduction User’s Manual...

  • Page 14: Overview

    2. Overview 2. Overview Specifications Table 2.1. Functional Specifications < 1 / 2 > Model IPC-PT/L630S(PCI)C IPC-PT/L630S(PCI)CP IPC-PT/H630X(PCI)C IPC-PT/H630X(PCI)CP Display LCD type 12.1-inch TFT color LCD, 15-inch TFT color LCD, XGA SVGA (800 x 600 dots) (1024 x 768 dots) Number of 260,000 colors...
  • Page 15 2. Overview Table 2.1. Functional Specifications < 2 / 2 > Model IPC-PT/L630S(PCI)C IPC-PT/L630S(PCI)CP IPC-PT/H630X(PCI)C IPC-PT/H630X(PCI)CP Keyboard I/F PS/2-type keyboard-compatible (6pin, MINI DIN connector) Mouse I/F PS/2-type mouse-compatible (6pin MINI DIN connector) RAS function WDT: 1sec - 255sec (RESET or external output is allowed at time expiration) Remote reset: External input signal Expansion board slot None...
  • Page 16 2. Overview Table 2.2. Installation Environment Requirements Parameter Requirement description Allowable instantaneous Less than 20ms Power supply One minute each for 3.0 kVAC (input-output), 2.0 kVAC (input-FG), power outage specifications and 0.5 kVAC (output-FG) Dielectric strength 50MΩ (DC500V) 0 - 50°C(SDD in use) Operating temperature 5 - 45°C(HDD in use) 5 - 45°C(FDD in use)
  • Page 17 2. Overview Display Optical Specifications Table 2.3. IPC-PT/L630S(PCI)C, IPC-PT/L630S(PCI)CP Parameter Condition Min. Typical φ = 180° 35deg 45deg View angle (Vertical) Display. φ = 0° 45deg 55deg CR≥10 Monochrome φ = +90° 50deg 60deg View angle (Horizontal) φ= -90° 50deg 60deg Contrast Display.

  • Page 18: System Configuration

    2. Overview System Configuration Display General-purpose analog input display *Using the bundled DVI-analog 2.5inch hard (silicon) RGB adapter disk drive Built-in Printer Main memory PCMCIA card slot 144pin SO-DIMM PCMCIA types I, II x 2, or III x 1 RS-232C LINE IN LINE OUT Option CD-ROM...

  • Page 19: External Dimensions

    2. Overview External Dimensions IPC-PT/L630S(PCI)C 4-M4 TAP (Maxium tapping length: 4mm) 12-M4 STUD 63.5 φ3 POWER 137.5 [mm] Figure 2.3. IPC-PT/L630S(PCI)C IPC-PT/L630S(PCI)CP 12-M4 STUD 24 2.4 [mm] Figure 2.4. IPC-PT/L630S(PCI)CP User’s Manual...
  • Page 20 2. Overview IPC-PT/H630X(PCI)C 4-M4 TAP (Maxium tapping length 12-M4 STUD : 4mm) 309.1 63.5 φ3 157.5 [mm] Figure 2.5. IPC-PT/H630X(PCI)C IPC-PT/H630X(PCI)CP 12-M4 STUD 309.1 [mm] Figure 2.6. IPC-PT/H630X(PCI)CP User’s Manual...
  • Page 21 2. Overview User’s Manual...

  • Page 22: Hardware Setup

    3. Hardware Setup 3. Hardware Setup Before Using the PANECON-PC for the First Time Follow the next steps to set up the PANECON-PC: STEP1 Install the hard disk and expansion main memory (DIMM) and set jumper switches. By referring to the information in this chapter, set the PANECON-PC.

  • Page 23: Hardware Setup

    3. Hardware Setup Hardware Setup Removing the Top Cover and HDD Bracket - Before you start, be sure that the power is turned off. - Remove only those screws that are explained. Do not move any other screw. (1) Remove the top cover. Figure 3.1.
  • Page 24 3. Hardware Setup (2) Remove the hard disk bracket. Figure 3.2. Removing the HDD Bracket User’s Manual...

  • Page 25: Locations And Settings Of Internal Connectors And Jumpers

    3. Hardware Setup Locations and Settings of Internal Connectors and Jumpers When you remove the top cover and hard disk bracket, the connectors, jumpers, and switches are laid out as shown in the figure below: IPC-PT/L630S(PCI)C, IPC-PT/H630X(PCI)C, IPC-PT/L630S(PCI)CP IPC-PT/H630X(PCI)CP Figure 3.3. Locations and Settings of Jumpers, Connectors, and Switches inside the Top Cover (IPC-PT/L630S(PCI)C, IPC-PT/L630S(PCI)CP,...
  • Page 26 3. Hardware Setup Table 3.1. Jumper List Factory setting Reference Function Remarks IPC-PT/L630S(PCI)C IPC-PT/H630XS(PCI)C Page IPC-PT/L630S(PCI)CP IPC-PT/H630X(PCI)CP Short 2-3 to clear JP1 Clear CMOS. 1 - 2 shorted 1 - 2 shorted ---- CMOS. Sets RS-485 2 - 3 shorted 2 - 3 shorted termination Used by the...

  • Page 27: Installing The Hard Disk

    3. Hardware Setup Installing the Hard Disk (1) Connect the provided HDD cable to the hard disk (silicon disk). Note! Connect the HDD cable in alignment with pins from the left end of the connector on the HDD side. Four master/slave setting pins are left unconnected on the right side.

  • Page 28: Installing The Main Memory (Dimm)

    Obtain the following special option products. - Package type :144pin Small Outline DIMM - Specifications :3.3V, PC133/CL3 - Capacity :256MB - Type :SDRAM - Optional memories * :PC-MSD256-144V * Operation is not guaranteed if memory parts other than CONTEC option products are used. User’s Manual...
  • Page 29 3. Hardware Setup Main Memory (DIMM) Installation Procedure The mounted SO-DIMM sockets vary depending on the type of the circuit board used. <Board type with single sockets on its front and back> This type of circuit board has single sockets on its front and back. The socket on the back is equipped with standard memory.
  • Page 30 3. Hardware Setup <Board type with a double socket on its front> This product has a double socket on the front of its circuit board. Standard memory is installed in the lower socket. To add more memory, install it to the upper socket. SO-DIMM Disconnection Procedure Open the levers on both sides slightly to the left and right.

  • Page 31: Fastening The Power Cable

    3. Hardware Setup Fastening the Power Cable Removing the Screw on the Metal Brace to Keep the AC Cord in Place In order to install the metal brace, temporarily remove the machine screw on the front left end. Remove this screw. Figure 3.7.
  • Page 32 3. Hardware Setup Figure 3.9. Installing the Metal Brace and the Clamp User’s Manual...

  • Page 33: Installation Procedure

    3. Hardware Setup Installation Procedure (1) Cut a panel in the following dimensions for installing the main unit. IPC-PT/L630S(PCI)C, CP IPC-PT/H630X(PCI)C, CP 12-φ5 12-φ5 [mm] Figure 3.10. Panel Opening Dimensions (2) Insert the supplied gasket between the panel and display and fasten them together with M4 nuts as shown below.

  • Page 34: Installation Requirements

    3. Hardware Setup Installation Requirements To restrict overheating, always mount the unit vertically. Similarly, to maintain the ambient temperature within the range specified in the specifications, ensure a clearance between the unit and surrounding equipment of at least 100mm for the top and rear and 50mm for the bottom and sides.
  • Page 35 3. Hardware Setup User’s Manual...

  • Page 36: Bios Setup

    Press the <F2> key at the keyboard. Phoenix BIOS 4.0 Release 6.0 Copyright 1985-2001 Phoenix Technologies Ltd. All Rights Reserved Copyright 2001, CONTEC CO., Ltd. IPC-BX/M630(PCW), IPC-Px/x630(PCW) series BIOS Ver. x.xx. CPU = Pentium III(R) Tualatin 512K-LP(133MHz/1.150) processor 800MHz Memory Speed = PC133...

  • Page 37: Main Menu

    4. BIOS Setup Main Menu PhoenixBIOS Setup Utility Main Advanced Security Power PC_Health Boot Exit Item Specific Help System Time: [00:55:20] System Date: [09/05/2002] <Tab>, <Shift-Tab>, or <Enter> selects field Legacy Diskette A: [1.44/1.25 MB "] Primary Master [No device] Primary Slave [No device] Secondary Master...
  • Page 38 4. BIOS Setup Primary Slave : Set the type of HDD(SDD) to be used as the second drive. Selecting this field changes the screen to the submenu for manually setting drive configuration data such as the number of cylinders. This field is set to [Auto] by default. You can leave it intact for normal use.

  • Page 39: Boot Features Window

    4. BIOS Setup Boot Features Window PhoenixBIOS Setup Utility Main Boot Features Item Specific Help Floppy check : [Disabled] Keyboard check : [Disabled] ↓ Select Item Help Change Values Setup Defaults ←→ Select Menu Esc Exit Enter Select Sub-Menu F10 Save and Exit Figure 4.3.

  • Page 40: Advanced Window

    4. BIOS Setup Advanced Window PhoenixBIOS Setup Utility Main Advanced Security Power PC_Health Boot Exit Item Specific Help Reset Configuration Data: [No] Installed O/S: [Other] Select 'Yes' if you PCI IRQ want to clear the PCI/PMP ISA UMB Region Exclusion Extended System PCI/PMP ISA DMA Resource Exclusion Configuration...
  • Page 41 4. BIOS Setup PCI/PNP ISA DMA Resource Exclusion: Start PCI/PNP ISA DMA Resource Exclusion as shown above. You can reserve DMA channels for devices. All UMB areas are unallocated by default. I/O Device Configuration: Start I/O Device Configuration as shown above. You can configure serial and parallel ports.
  • Page 42 4. BIOS Setup BIOS DDC : Specify whether to enable or disable DDC. Plese set to [Enabled]. Start Wait : Sets the wait time for the startup of BIOS and enables timing adjustment for devices connected to the main unit. [Disabled], [5sec], [10sec], [15sec], [20sec], [25sec], or [30sec] can be selected.

  • Page 43: I/O Device Configuration Window

    4. BIOS Setup I/O Device Configuration Window PhoenixBIOS Setup Utility Advanced I/O Device Configuration Item Specific Help Serial Port A : [Enabled] Configure port Base I/O address : [3F8] using options: Interrupt : [IRQ 4] Serial port B : [Enabled] [Disabled] Base I/O address : [2F8]...
  • Page 44 4. BIOS Setup Fields available with Parallel port set to [Enabled] Base I/O address Set to base I/O address. Interrupt Set to IRQ. Mode Set to parallel port's operating mode. DMA channel This is the DMA channel setting used when ECP is selected during parallel-port mode setting.

  • Page 45: Security Window

    4. BIOS Setup Security Window PhoenixBIOS Setup Utility Main Advanced Security Power PC_Health Boot Exit Item Specific Help Set Supervisor Password : [Enter] Set User Password : [Enter] Supervisor Password controls access to the Supervisor Password Is : Clear setup utility. User Password Is : Clear Password on boot :...

  • Page 46: Power Window

    4. BIOS Setup Power Window PhoenixBIOS Setup Utility Main Advanced Security Power PC_Health Boot Exit Item Specific Help Enable ACPI : [No] ACPI Supend Mode : [Disabled] Select 'Yes' if you want to clear the APM Capabilities : [Disabled] Extended System Configuration Power Saving : [Disabled]...

  • Page 47: Pc-Health Window

    4. BIOS Setup PC-Health Window PhoenixBIOS Setup Utility Main Advanced Security Power PC_Health Boot Exit Item Specific Help Hardware Monitor Setup Thermal1_0 (System1): +32°C / +89°F Thermal1_1 (CPU): +56°C / +132°F FAN_0 : 0 RPM FAN_1 : 0 RPM +5V : +4.97V +3.3V : +3.28V...

  • Page 48: Boot Window

    4. BIOS Setup Boot Window PhoenixBIOS Setup Utility Main Advanced Security Power PC_Health Boot Exit Item Specific Help *Removable Devies Keys used to view or configure devices : *Hard Drive <Enter> expands or CD-ROM Drive collapses devices with Network Boot a + or - <Ctrl + Enter>...

  • Page 49: Exit Window

    4. BIOS Setup Exit Window PhoenixBIOS Setup Utility Main Advanced Security Power PC..Health Boot Exit Item Specific Help Exit Saving Changes Exit Discarding Changes Exit System Setup and Load Setup Defaults save your changes to Discard Changes CMOS. Save Changes Model : IPC-BX/M630(PCI), IPC-Px/x630(PCI) System BIOS : Vx.xx_xxx...

  • Page 50: Each Component Function

    5. Each Component Function 5. Each Component Function Component Identification IPC-PT/L630S(PCI)C, IPC-PT/H630X(PCI)C POWER LED HDD LED AC INLET POWER SW PCMCIA PRINTER RESET UTP (Ethernet) SERIAL1 SERIAL2 KeyBoard MOUSE LINE IN LINE OUT POWER LED LCD, Touch Panel SECONDARY IDE Figure 5.1.
  • Page 51 5. Each Component Function IPC-PT/L630S(PCI)CP, IPC-PT/H630X(PCI)CP POWER LED HDD LED AC INLET POWER SW PCMCIA PRINTER RESET UTP (Ethernet) SERIAL1 Expansion Slot PCIx 2 SERIAL2 KeyBoard MOUSE LINE IN LINE OUT POWER LED LCD, Touch Panel SECONDARY IDE Figure 5.1. Component Identification < 2 / 2 > User’s Manual...
  • Page 52 5. Each Component Function Table 5.1. Component Functions Component Function LINE IN Line in (φ3.5 PHONE JACK) LINE OUT Line out (φ3.5 PHONE JACK) Microphone input (φ3.5 PHONE JACK) Keyboard connector (MINI-DIN, 6pin) MOUSE PS/2 mouse connector (MINI-DIN, 6pin) SERIAL1 Serial port 1 connector (9pin, male D-SUB) SERIAL2 Serial port 2 connector (9pin, male D-SUB)

  • Page 53: Line In Interface

    The audio driver is required to use the line input, line output, and microphone input interfaces. Visit the CONTEC web site to download the audio driver (IPC-SLIB-01) for the OS running on your PANECON-PC. For the download, see Chapter 7 “List of Options".

  • Page 54: Keyboard Interface

    5. Each Component Function Keyboard Interface The PANECON-PC is equipped with a keyboard connector named KB (MINI-DIN 6P). Table 5.2. Keyboard Connector Connector type Equivalent to the MD-DS12300-14S-14 (JST) Signal Pin No. Pin No. Signal +KBD DATA +KBD CLK N.C. N.C.

  • Page 55: Serial Port Interface

    5. Each Component Function Serial Port Interface Serial port A and B(RS-232C Ports) The PANECON-PC is equipped with two RS-232C-compliant serial port connectors (SERIAL1: Serial port A and SERIAL2: Serial port B). You can use BIOS Setup (described in Chapter 3) to configure an I/O address, interrupt and unused state for each of the ports independently.
  • Page 56 5. Each Component Function Serial port C(touch panel) One channel of serial port is provided for use as a touch panel connector. You can use BIOS Setup (described in Chapter 3) to configure an I/O address, interrupt and unused state for this port. (The same I/O address and IRQ cannot be shared with any other device.) Table 5.6.
  • Page 57 5. Each Component Function Output connector with the RS-422/RS-485 mounted (factory default) Table 5.8. Output connector with the RS-422/RS-485 mounted (RAS Connector) Pin No. Signal Meaning TX + Transmitted data + TX - Transmitted data - RX + Received data + RX - Received data - Reference...
  • Page 58 5. Each Component Function Control of Transmitted Data in Half-Duplex Mode In half-duplex mode, the transmission buffer needs to be controlled in order to prevent collision of transmitted data. The PANECON-PC uses RTS and controls the buffer with modem control register's bit 1. Transmission and reception gate control by the register setting of port address 4006h and 4007h is allowed only for the RS-422/485 (Serial port D).
  • Page 59 5. Each Component Function Table 5.10. Function of Each Register < 1 / 4 > I/O address Description 03F8H THR: Transmitter Holding Register [DLAB=0] bit0 bit7 Register dedicated to write transmitted data to 03F8H RBR: Reciever Buffer Register [DLAB=O] bit0 bit7 Register dedicated to read received data from 03F8H...
  • Page 60 5. Each Component Function Table 5.10. Function of Each Register < 2 / 4 > I/O address Description 03FAH IIR : Interrupt Identification Register Interrupt details 1: Do not generate interrupts 0: Generate interrupts bit2 bit1 bit0 Priority Description Interrupts are not generated. Generated by overrun, parity, framing error or break 1 (high) interrupt.
  • Page 61 5. Each Component Function Table 5.10. Function of Each Register < 3 / 4 > I/O address Description 03FCH MCR: Modem Control Register Loop IRQ RTS DTR 0 : Inactive [HIGH] 1 : Active [LOW] RTS 0 : Inactive [HIGH] 1 : Active [LOW] Interrupt control bit...
  • Page 62 5. Each Component Function Table 5.10. Function of Each Register < 4 / 4 > I/O address Description 03FEH MSR : Modem Status Register DSR CTS DDCD TERI DDSR DCTS Delta CTS Delta DSR Since these statuses are Trailing edge RI not used with Delta data carrier detect RS-485, data...

  • Page 63: Floppy Disk Interface

    5. Each Component Function Floppy Disk Interface The PANECON-PC is equipped with a FD controller to allow one FD drive to be connected to the FD connector named FD on the front end. Use the FD drive that is available as a dedicated option. Table 5.12.

  • Page 64: Usb Ports

    5. Each Component Function USB Ports The PANECON-PC is equipped with two USB interface channels. Table 5.13. USB Connector Signal Signal Pin No. Pin No. USB0 Vcc USB1 Vcc USB0 -Data USB1 -Data USB0 +Data USB1 +Data USB0 GND USB1 GND User’s Manual...

  • Page 65: Ethernet

    : Normal connection indicator : Full-duplex mode indicator 100M : 100M-operation indicator LAN drivers Visit the CONTEC web site to download the LAN driver (IPC-SLIB-01) for the OS running on your PANECON-PC. For the download, see Chapter 7 “List of Options". User’s Manual...

  • Page 66: Pc Card Slots

    5. Each Component Function PC Card Slots PCMCIA compliant, CardBus compatible card slots are provided. [TYPE II x 2 (TYPE III x 1) size] Slot 1 Slot 2 Figure 5.3. Slot Numbers and Locations Note! A type III card should be inserted into slot 2. Attaching the Metal Brace to Keep the Card in Place Get the tips caught...

  • Page 67: Dvi Interface

    5. Each Component Function Power Supply to the Card The voltage that can be used and the current capacity of each slot are as shown below: Table 5.15. Power Supply to the Card Voltage Current capacity (Max.) 1A/Slot +3.3V 1A/Slot +12V Not supplied.
  • Page 68 BLUE N.C. N.C. DDC DATA HSYNC VSYNC DDC CLK Display Driver Visit the CONTEC web site to download the Display driver (IPC-SLIB-01) for the OS running on your PANECON-PC. For the download, see Chapter 7 “List of Options". User’s Manual...

  • Page 69: Printer Port Interface

    5. Each Component Function Printer Port Interface A printer port is provided. You can use BIOS Setup to configure an operation mode, I/O address, interrupt, DMA channel and unused state for this port. The connector is named PRINTER. Table 5.18. Printer Ports and I/O Addresses I/O address Interrupt 3BCh - 3BFh...

  • Page 70: Ras Functions

    5. Each Component Function RAS Functions A RAS port is provided. This port offers watchdog timer, remote reset, and general-purpose I/O RAS functions. Table 5.20. RAS Connector Connector type 15pin D-SUB(FEMALE) (DALC-J15SAF-20L9) JAE Pin No. Signal Function External speaker signal External speaker ground TX + RS-485 transmitting line...

  • Page 71: Watchdog Timer

    5. Each Component Function Watchdog Timer The watchdog timer is started by output of A5 to I/O port address 4002h. A second output of A5 to the same port within the specified expiration time once again triggers the watchdog timer. If a time-out occurs, a reset or an interrupt is generated according to the 4004h port setting or an alarm is output according to the 4004h port setting.
  • Page 72 5. Each Component Function How to Use the Watchdog Timer BIOS setting Power ON Set event Output data to ports 4001h and 4004h to set the counter clock. output control Read port 4002h, stop the WDT, and turn off alarm Instruct output.
  • Page 73 5. Each Component Function * 4001h (bit4-6): Alarm out output control WD_S1 WD_S0 PO2_M RESET PIM2 PIM1 PIM0 R/W (default: XXXX0000b) Figure 5.6. Alarm Out Output Control Port (4001h) PO2_M : PO PO2/WDT pin output setting Set the RAS connector's PO2/WDT(12) signal to PO2 (general-purpose output).
  • Page 74 5. Each Component Function * 4003h: WDT counter Figure 5.8. WDT Counter Port (4003h) Writes watchdog timer count data. Write watchdog timer counter expiration time data. 1sec → 8sec → 15sec → 30sec → * 4004h : Event output control RESET R/W (Default: XXXX0000b) Figure 5.9.
  • Page 75 5. Each Component Function * 4005h : RAS status port (Default: XXXXXXX0b) Figure 5.10. RAS Status Port (4005h) RAS status port WDT: WDT status This is the WDT status bit. This bit is cleared when the WDT stops (read port 4002h).

  • Page 76: General-Purpose I/O And Remote Reset

    5. Each Component Function General-purpose I/O and Remote Reset The PANECON-PC is equipped with three general-purpose insulated signals each for input and output. The input signals can also be used for interrupt input or remote reset input. Specifications [ Input ] - Input specifications : Current-driven input by opto-coupler insulation.
  • Page 77 5. Each Component Function I/O Addresses and Instructions * 4000h: General-purpose I/O PIO2 PIO1 PIO0 Figure 5.12. General-purpose Input Port (4000h) Read data from PI0, PI1 and PI2. Set data to be output to PO0, PO1 and PO2. * 4001h (bit0-3): PI2/IRQ(14) event input control WD_S1 WD_S0 PO2_M...
  • Page 78 5. Each Component Function * 4006h: Index address setting Figure 5.14. Index Address Setting Port (4006h) Index address setting When specifying the RS-485 setting with port 4007h, output 00h to this port before you specify the setting. (* Index addresses other than 00h are used by the system.
  • Page 79 5. Each Component Function Note! A bit indicated with "rsv" is used by the system. Do not modify the bit. 0 : Controlled by RTS TE_SEL 1 : Controlled by TE_GATE 0 : Transmission prohibited 1 : Transmission permitted RX-(11) 0 : Transmission permitted TE_GATE RX+ (3)
  • Page 80 5. Each Component Function External I/O Circuit (External circuit) (PCOM) 4.7kΩ 4.7kΩ (IN) 1/4W PC817 External power (12V - 24VDC) Internal reset Input (PI 0 - 2) contact RAS connector Figure 5.18. Input Circuit (External circuit) Lard (PO 0 - 2) External power 510Ω...

  • Page 81: Reset Switch

    5. Each Component Function Leave all the S1 bits untouched as they are used by the system. IPC-PT/L630S(PCI)C, CP IPC-PT/H630X(PCI)C, CP Figure 5.20. Factory Settings Reset Switch The PANECON-PC is equipped with a hardware reset switch. To prevent it from being pressed by mistake, the switch is designed to be difficult to press.

  • Page 82: Ide Interface

    5. Each Component Function IDE Interface Connector for the Internal Drive (Primary IDE Connector) The PANECON-PC is equipped with an E-IDE controller to allow a 2.5inch IDE hard disk to be connected to connector CN1 on the board. Table 5.26. Primary IDE Connector (CN6) Connector in use 44-socket header type (2mm pitch) Pin No.
  • Page 83 Secondary IDE Connector-CN2 Use the dedicated option cable to connect the option CD-ROM drive. The cable is not intended to connect devices (such as hard disks) other than CONTEC option products. Table 5.27. Secondary IDE Connector (CN2) Connector in use 40pin, half-pitch type (1.27mm pitch)

  • Page 84: Expansion Slots (Cp Model)

    5. Each Component Function Expansion Slots (CP Model) The CP model has two PCI bus expansion slots to hold PCI bus boards. Board Dimensions Allowed 240mm(Max.) Figure 5.21. Expansion Board Dimensions Note! A board that uses the back of the board edge connector (the shaded area in the figure) may not be mounted.

  • Page 85: Board Installation Procedure

    5. Each Component Function Board Installation Procedure (1) Be sure the power is turned off. (2) Remove the top cover. Figure 5.22. Removing the Top Cover (3) Remove the brace that holds the printed circuit board (PCB) down. Remove the screws on the brace. The brace will separate toward you.
  • Page 86 5. Each Component Function (4) Insert the board into the slot and fasten it with screws. Figure 5.24. Installation of an Expansion Board (5) Install the PCB brace. It can hold down a board if its height is at least 68mm. Figure 5.25.
  • Page 87 5. Each Component Function (6) Replace the expansion slot cover. Figure 5.26. Replacing the Top Cover User’s Manual...

  • Page 88: Touch Panel

    (The I/O addresses or IRQ cannot be shared with any other device.) Visit the CONTEC web site to download the touch panel driver (IPC-SLIB-01) for the OS running on your PANECON-PC. For the download, see Chapter 7 “List of Options".
  • Page 89 6. Touch Panel Points to note when installing the touch panel driver 1. Which Windows COM port number is allocated to the serial port used as the communication interface to the touch panel (Serial Port C)? (The standard setting is COM3.) 2.

  • Page 90: Appendix

    7. Appendix 7. Appendix Memory Map FFFFFFF Expansion memory area 0100000 00FFFFF Main BIOS (128KB) 00E0000 00DFFFF Expansion ROM area (Free to the user) 00D0000 00CFFFF Reserved for BIOS 00CC000 00CBFFF VGA BIOS (48KB) 00C0000 00BFFFF Video RAM area (128KB) 00A0000 009FFFF (640KB)

  • Page 91: I/O Port Addresses

    7. Appendix I/O Port Addresses Table 7.1. I/O Port Addresses < 1 / 2 > ADDRESS(HEX) Description Remark 000-00F DMA controller 1 (slave) ch0 - 3 (8-bit transfer) 010-01F Reserved for system 020-03F Interrupt controller 1 (master) 040-05F Timer 060-06F Keyboard controller 070-07F RTC, NMI mask...

  • Page 92: Interrupt Level List

    7. Appendix Table 7.1. I/O Port Addresses < 2 / 2 > ADDRESS(HEX) Description Remark CF0-CFF Reserved for system 4000-4007 RAS functions 4008-400F Reserved for system 46E8 Reserved for system 83D0-B3D3 Reserved for system Interrupt Level List Table 7.2. Hardware Interrupt Levels (Factory Settings) Type 8259 Priority...
  • Page 93 7. Appendix User’s Manual...

  • Page 94: List Of Options

    8. List of Options 8. List of Options Memory for extension (144pin SO-DIMM) - PC-MSD256-144V 256MB SD memory module Silicon disk drive for extension (IDE 2.5inch) [PCI Board Type] For IPC-PT/L630S(PCI)CP, IPC-PT/H630X(PCI)CP - PC-RSD1000-PCI 1GB silicon disk drive - PC-RSD2000-PCI 2GB silicon disk drive - PC-RSD4000-PCI 4GB silicon disk drive...
  • Page 95 *2 You can download the driver from the Download Library (http://www.contec.com/download) on the CONTEC web site. If you need IPC-SLIB-01 (CD-ROM version), it is available as a separately priced option. Check the CONTEC’s Web site for the latest information on these options. User’s Manual...

  • Page 96: User's Manual

    3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan Japanese http://www.contec.co.jp/ English http://www.contec.com/ Chinese http://www.contec.com.cn/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. [09202007] [03102003] Management No. A-46-646 [09202007_rev8] Parts No. LYBN883...
