3 About the Software
Analyzer Schematic Icons (continued)
Description
Icon or Symbol
Pressure and temperature readings. Displays for either the expansion
chamber or the sample chamber, depending on the unit configuration.
Gas flow direction.
Instrument Schematic Shortcut Menus
Each manually controlled schematic component has a shortcut menu displaying the operations
available for that particular component. To access the shortcut menu, hover the mouse pointer over
the component and right click.
Schematic Shortcuts
Icon or Symbol
Valve options
3 - 12
Description
Close. Closes the selected valve.
Open. Opens the selected valve.
