7 About Reports
7. In the Report Options tab, click Overlays.
8. On the Overlays window, move up to 25 files from the Available Files box to the Selected Files
box. If the files to be overlaid do not display in the Available Files list, click the Browse icon to
locate and select which graphs are to be overlaid.
9. Click OK.
10. Go to Reports > Start Report. Select the report destination in the Settings group box. Select
the overlay file name in the Files list box, then click OK.
11. In the pop-up Selected Reports list box, reports can be added or removed by double clicking
the entry. Selected reports are indicated by a checkmark to the left. Click OK.
12. Reports display in a tabbed format. Click each tab to view each report.
Overlay Sample Selection
Field
Status [drop-down box]
Look in [button]
Available Files
[selection]
Selected Files
[selection]
For fields and buttons not listed in this table, see
tons on page 3 -
7 - 18
Example of Overlay window
Description
Select the status of files to be combined.
Click the Browse icon to change the file folder location.
Lists files that meet the selected criteria. Select the files to be com-
bined, then click Add. The selected files are moved to the Selected
Files list box.
Lists the files selected to be combined. Click
2.
OK to combine the files.
Common Fields and But-
