2 Data Entry with Keypad
T D
RANSMIT ATA
Transmitted Data on page D - 1
n
The AccuPyc RS232 interface transmits report data to a computer using the standard ASCII file
format. Reports may be transmitted in a single column format or a spreadsheet format.
Press Alt + 3 to transmit report data.
n
Press Alt + CLEAR to cancel report data transmission.
n
A P
NALYSIS ARAMETERS
This option enables specific analysis and calibration parameters. Although the Setup Type is shown
as Analysis Parameters, these same prompts are used to specify calibration parameters. The
pycnometer is shipped with default values; however, these settings may be modified to meet
laboratory requirements.
After each selection, press Enter to display the next prompt. If data results are to be e-mailed
automatically after analysis, specify e-mail parameters using the instructions in the AccuPyc II 1345
Installation Instructions and Checklist [part number 134-42875-02].
Enter appropriate analysis and report parameters for the current analysis. The chosen or specified
parameters in Set Up determine what prompts and information are displayed for the analysis.
Display Text
Setup Type?

Analysis Parameters

Number of Purges:
Purges fill pressure
2 - 10
Description
Press ENTER to accept Analysis Parameters.
Key in the number of purges to be performed. Purging cleans the
sample cell and expansion chambers before an analysis begins. The
greater the number of purges, the cleaner the sample will be when
analyzed.
The range is 0 to 999. For calibration, 10 is sufficient.
Key in the fill pressure. For most applications, the default of 19.500
psig is adequate. Typically, the greater the fill pressure, the easier it is
to measure the volume precisely. However, a lower pressure may be
required for some samples.
The range in psig is 0 to 19.850.
The range in kPag is 0 to 136.86.
High Pressure sample chamber:
AccuPyc II 1345 Operator Manual
134-42851-01 (Rev A) — Jan 2021
