A Advanced Reports - Python Module
graphtype --- graph type; (default = 'both')
interpolation -- linear or akima spline interpolation (default='akima')
A C U
DD A URVE SING THE
This script adds a curve to the last created graphical report using the second y-axis:
mic.graph.addyy(name, xx, yy):
Add a curve to the last created graphical report using the second
y-axis. The arguments to this call are the same as to mic.graph.add.
C N G
REATE A EW
mic.graph(title='User Graph', xlabel='X axis', ylabel='Y axis', yylabel='YY
axis',
xlinear=True, ylinear=True, yylinear=True,
xinvert=False, yinvert=False, yyinvert=False,
xrange=None, yrange=None, yyrange=None,
xbars_id=''):
Keyword arguments:
title --- the graphical report title (default = 'User Graph')
xlabel --- x-axis label (default = 'X axis')
ylabel --- y-axis label (default = 'Y axis')
yylabel --- yy-axis label (default = 'YY axis')
xlinear --- x-axis linear scale; if false, use log scale
(default = True)
ylinear --- y-axis linear scale; if false, use log scale
(default = True)
yylinear --- yy-axis linear scale; if false, use log scale
A - 4
'o' or '0' : circle
'x' : cross
'^' : up triangle
'v' : down triangle
's' : square
'd' : diamond
'8' : hourglass
'~' : horizontal hourglass
'' or None : no marker
'a' : automatically selected
'curve' or 'c' : curve
'points' or 'p' : points
'both' or 'b' : curve-and-points
'hist' or 'h' : histogram
'akima' use akima spline
'linear' use linear interpolation
S Y-A
ECOND
R
RAPHICAL EPORT
XIS
