16 Multigas Option
C G
ONNECT ASES
1. Connect one end of the gas supply tubing to the gas supply.
2. Insert the other end of the tubing into one of the valve inlets on the multigas assembly.
3. The faceplate of the valve assembly contains four sections; one for each gas inlet on the
assembly. Write the name of the gas in the applicable section.
S G
ELECT ASES
After installing the gases, use the knob to select the gas. Purge the gas lines when changing gases.
16 - 2
Turn the knob to select the gas
Write the name of the gas connected to
the inlet
