15 MultiVolume Insert Option
5. If using a fritted filter cap, place it onto the top of the insert.
6. Replace the sample chamber cap.
To Remove the Insert
1. Remove the sample chamber cap and place on a clean work surface with the greased side
facing upward.
2. Remove the fritted filter cap (if used).
3. Insert the handling tool into the sample cup until the sample cup is gripped by the O-ring.
4. Lift the sample cup out of the insert.
5. Pull the insert from the sample chamber.
6. Replace the sample chamber cap.
CM 3
10, 3.5, 35
AND
Remove the chamber cap and place the insert into the sample chamber. The insert should fit snugly
in the chamber. Place the appropriate sample cup into the well of the insert.
Do not force the insert or cup into the openings. This may damage the instrument, insert,
or sample cup.
Install the fritted filter cap (if used) before closing the sample chamber. A fritted filter cap is used to
constrict gas flow and is included with some inserts. The fritted filter cap for the 10 cm
the top of the sample cup. The fritted filter caps for the 1 and 3.5 cm
insert. Fritted filter caps are not available for the 0.1 and 35 cm
15 - 4
I
NSERTS
3
3
inserts fit on the top of the
3
inserts.
AccuPyc II 1345 Operator Manual
134-42851-01 (Rev A) — Jan 2021
insert fits on
