Diagnostics Using The Software - Micromeritics ACCUPYC II 1345 Operator's Manual

9 D
IAGNOSTICS USING THE
Unit [n] > Diagnostics
Performs a leak test for the analysis module.
Diagnostic Test
Field or Button
Estimated time
File
Live Graph
Next [button]
Operator [text box]
Repeat [button]
AccuPyc II 1345 Operator Manual
134-42851-01 (Rev A) — Jan 2021
S
OFTWARE
A. Suspend/Resume/Skip buttons
B. Port report buttons
C. Live graph settings
Description
Amount of time it takes to run the test.
Shows a status bar of steps complete once the test begins.
Select graph settings.
Starts the next test.
Name of the operator performing the diagnostic.
Repeats the test.

9 Diagnostics using the Software

9 - 1
