Figure 2-2: The Specific Chip Model Definition of ZYNQ7000 Series
Figure 2-3: The XC7Z100 chip used on the Core Board

Part 3: DDR3 DRAM

The FPGA core board AC7Z100 is equipped with four Micron 512MB
DDR3 chips,
MT41K256M16HA-125), in which Two DDR3s are mounted on the PS and PL
8 / 33
ZYNQ FPGA Development Board AC7Z100 User Manual
model MT41J256M16HA-125
Amazon Store: https://www.amazon.com/alinx
(compatible with
