Part 11:
Assignment
The core board has a total of four high-speed expansion ports. It uses four
120-pin inter-board connectors (J29~J32) to connect to the carrier board. The
connector uses the Panasonic AXK5A2147YG, and the connector type
corresponding to the carrier board is AXK6A2337YG. J29 connects BANK10 IO
and BANK11 IO, J30 connects GTX transceiver signal, J31 connects JTAG and
BANK35 IO (1.8V level standard), J32 connects PS MIO, IO and +5V power
supplies of the BANK11, BANK12
Pin assignment of J29 connector
J29 Pin Signal Name
1 B11_L4_N
3 B11_L4_P
5
7 B11_L3_P
9 B11_L3_N
11
13
15 B11_L2_P
17
19
21 B11_L5_P
23
25 B11_L15_P
27 B11_L15_N
29
31 B11_L13_N
25 / 33
ZYNQ FPGA Development Board AC7Z100 User Manual
Board to
ZYNQ Pin
Number
AJ24
AJ23
GND -
AJ21
AK21
GND -
B11_L2_N AK23
AK22
GND -
B11_L5_N AH24
AH23
GND -
AJ20
AK20
GND -
AH21
Amazon Store: https://www.amazon.com/alinx
Board Connectors
J29 Pin Signal Name
2 B11_L1_N
4 B11_L1_P
6 GND
8 B11_L8_N
10 B11_L8_P
12 GND
14 B11_L12_N
16 B11_L12_P
GND
18
20 B11_L16_N
22 B11_L16_P
24 GND
26 B11_L6_N
28 B11_L6_P
30 GND
32 B11_L17_N
Pin
ZYNQ Pin
Number
AK25
AJ25
-
AG25
AG24
-
AF22
AE22
-
AK18
AK17
-
AH22
AG22
-
AJ19
