Inside the Printer
Ribbon Cartridge
Handle
Printhead
Manual Advance
Knob
Ribbon Cartridge
Handle
Ribbon Cartridge or
Cassette
EM1, EM2 Card Printers User's Guide
Printhead
Manual Advance
Knob
The printhead transfer the card images to the card using the print
ribbon.
The knob moves a card in the track to clear a card jam.
Lift up the handle on the ribbon cartridge or cassette to remove it
from the printer.
The ribbon cartridge or cassette holds the print ribbon and cleaning
roller.
Ribbon Cartridge
or Cassette
7
