(b) Odometer/Tripmeter/
Service reminder indicator
The odometer (1) shows accumulated
distance traveled.
The tripmeter (2) shows distanced traveled
per trip. The tripmeter can be reset to zero by
pressing the reset button (3)
The service reminder indicator (4) is to
indicate user to bring the vehicle to an
Authorised
Hero MotoCorp
service. The indicator shall start blinking when
the vehicle covers kilometers as specified in
the maintenance schedule. The indicator will
keep on blinking throughout the kilometer
interval for a particular service and will stay
''ON'' thereafter.
The service reminder indicator can be reset at an
Authorised
Hero MotoCorp
4
3
(1) Odometer (2) Tripmeter (3) Reset button
(4) Service reminder indicator
workshop for
workshop.
1
2
15
After getting the vehicle serviced, make sure
that the service reminder indicator has been
reset.
FEATURES
Steering lock
Steering lock with ignition switch, turn the
ignition key (1) to "OFF" ( ) position & turn
the handle bar towards left or right & push the
key downwards & turn towards "LOCK"
position. After locking take out the key.
(1) Ignition key

HANDLEBAR SWITCHES CONTROL

Left handlebar controls
1. Passing switch
Gives an indication for passing ahead.
Press passing lamp switch(1) to operate the
passing lamp.
NOTE
1
