Vehicle Views - HERO SPLENDOR iSMART PROGRAMMED FI Manual

TOP VIEW
6
5
4
3
2
1
(1) Turn signal switch
(2) Horn switch
(3) Dimmer switch
(4) Clutch lever
(5) Passing switch
(6) Rear view mirror
(7) Neutral indicator
(8) i3s indicator
(9) Side stand indicator
(10) Fuel gauge
(11) High beam indicator
(12) Speedometer
(13) Turn signal indicator
*Accessories and features shown may not be part of standard fitment.

VEHICLE VIEWS

7 8 9 10 11 12
(14) Programmed FI malfunction indicator
(15) Odometer
(16) Tripmeter
(17) Service reminder indicator
(18) Master cylinder
(19) i3s switch
(20) Front brake lever
(21) Throttle grip
(22) Electric starter switch
(23) Reset button
(24) Ignition switch with steering lock
(25) Fuel tank cap
2
13 14 15 16 17 18
lamp (MIL)
19
20
21
22
23
24
25
