PARTS FUNCTION

Ignition switch

"OFF"( )
position/
Lock open
"LOCK" position
Key position
The engine can be started, turn signal lamps,
horn, tail/stop lamp and passing switch can be
operated. Fuel gauge, odometer and tripmeter
"ON" ( )
reading will be functional. Programmed FI
malfunction indicator lamp (MIL) illuminates.
i3s indicator glows for few seconds.
Engine cannot be started and no electrical
"OFF"( )
system will be functional.
"LOCK"
Steering can be locked.
"ON" ( )
position
1
(1) Ignition switch
(2) Ignition key
(3) Steering lock position
Function
12
2
3
Key removal
Key cannot be removed
Key can be removed
Key can be removed
