off in 5 sec onds . (The vehicle should be in
stand still condition, with
at less th n a 2000 r/min with
lever/throttle is in released position and
engine is warmed up The i3s indicator will
be continuously blinking in the speedometer
indicating that vehicle stopped in i3s
condition. By pressing the clutch lever, the
engine will start again and gear can be
engaged to move the vehicle.
If vehicle stops in i3s condition and kept idle
•
for more than 500 secs (ignition switch is
"ON" position) i3s function will be
deactivated and cannot be started by
pressing the clutch lever, rider can only
start the vehicle with electric or kick start.
If engine is stopped by any means other than
•
i3s function, i3s indicator will not glow/blink
in the speedometer. In this condition, vehicle
will not start by pressing the clutch lever.
Vehicle can be started by using kick or electric
start.
If all the required i3s conditions are met,
•
i3s indicator will glow for 5 secs before the
engine cuts-off.
Driving with i3s switch in "OFF" position:
While driving in a traffic jam/or very dense
traffic where the vehicle has to encounter a
stop and go situation, the i3s switch can be
changed to "OFF" position. Once this is done,
the i3s system will not work and the vehicle
will be in normal operating conditions as other
vehicles and no special functions will be
performed.
neutral gear position
clutch
).
NOTE
The i3s system will not function if rider puts
•
the i3s switch to"OFF" position.
If the battery voltage is low and engine r/min
•
is less than 2000, there will be 3 continuos
blinks after every 6 secs.
If the low battery voltage is detected while
•
the ignition key is in "ON" position or engine
is in running condition, the i3s function will
be deactivated or may not function properly
until the rider turns the ignition switch to
"OFF" ( ) position and then back to "ON"
( ) position.
If the vehicle is driven without battery or with
•
the dead battery and the engine r/min is less
than 2000 . The i3s indicator on the
speedometer will
1.5 secs.
If the vehicle has fallen down,
•
may not work properly. B efore restarting the
engine you must turn the ignition switch to
"OFF" ( ) position and then back to "ON"
( ) position.
If the battery is in healthy condition and the
•
i3s system does not work properly, it is
recommended to visit your Authorised
workshop.
MotoCorp
i3s system will not function properly if the
•
vehicle battery is low/dead or driven without
battery.
If vehicle diagnoses with any problem in
•
electronic control unit (ECU) the i3s function
will not work.
18
NOTE
blink continuously at every
i3s function
