Fuse Replacement - HERO SPLENDOR iSMART PROGRAMMED FI Manual

Remove the battery clamp (5).
•
Disconnect the negative (-)ve terminal lead
•
(6) from the battery first, then disconnect
the positive (+)ve terminal lead (7).
6
8
(5) Battery clamp
(7) (+)ve terminal
Pullout the battery
•
Battery installation
Reinstall in the reverse order of removal. Be
•
sure to connect the positive (+) terminal
first, then the negative (-) terminal.
Check all fasteners are secured properly.
•

FUSE REPLACEMENT

Fuse box :
(1) Location: Mounted on the
cleaner assembly 2 ( ).
Fuse ype: t
Blade fuse
In circuit fuse ( ) : 15A, 10A, 10A 3
Spare fuse ( ) : 15A, 10A 4
7
5
(6) (-)ve terminal
(8) Battery
(8) from the battery box.
ve
ve
, 10A
2 4
(1) Fuse box
(3) In circuit fuse: 15A, 10A, 10A & 10A
(4) Spare fuse: 15A & 10A
Never use a fuse with a different rating from
•
that specified. It may lead to serious damage
to the electrical system or a fire due to short
circuit.
Battery gives off explosive gases. Keep
•
sparks, flames & cigarettes away.
GOOD FUSE
air
57
3
1
(2) Air cleaner assembly
WARNING
! !
BLOWN FUSE
