HANDLEBAR SWITCHES CONTROL

Left handlebar controls
1. Headlamp dimmer switch/
Pass switch
The headlamp operates only when the engine
is running.
Press the switch (1) upwards for high beam
" " downwards for low beam "
Press the pass switch to "PASS" position to
operate the pass lamp.
2. Turn ignal amp witch s l
Shift the turn signal switch
r ight/ eft indications and leave it to come l
back to its normal position on its own.
IMPORTANT : To switch "OFF" the turn
signal after completing the turn, gently push
the switch inside.
3. Horn witch s ( )
Press the switch to operate the horn
".
s ( )
(2) sideways for
(3) .
1
2
(1) Headlamp dimmer switch/Pass switch
(2) Turn signal switch
4. Clutch switch
There is a clutch switch (4) provided for the
safety of the rider. The vehicle cannot be
started by electric starter switch until the clutch
lever is operated when the vehicle is engaged
in gear.
(4) Clutch switch
28
3
(3) Horn switch
