HERO SPLENDOR iSMART PROGRAMMED FI Manual page 8

RIGHT SIDE VIEW
15
16
1
(1) Pillion foot rest
(2) Kick starter pedal
(3) Rider footrest
(4) Rear brake pedal
(5) Oil level dipstick
(6) Starter motor
*Accessories and features shown may not be part of standard fitment.
14
2 3 4
(7) Leg guard
(8) CCB valve (inside)
(9) Caliper assembly
(10) Front disc
(11) Front suspension
4
5 6 7 8 8
( ) Headlamp 12
(1 ) Front visor 3
(14) Throttle body/ECU (inside)
(1 ) ear 5 R shock absorber
(16) Exhaust muffler
13
12
11
9 10
