Seat Lock/Helmet Holder - HERO SPLENDOR iSMART PROGRAMMED FI Manual

Do not overfill the tank. There should be no
•
fuel (4) in the filler neck (5).
For locking, position the cap with " "
•
mark facing towards the front, back on the
opening and press gently. The key springs
back to the normal position and the cap
gets locked.
CAUTION
! !
Do not park the vehicle under direct sunlight
as it causes evaporation of petrol due to heat
and deterioration of paint gloss due to ultra
violet rays.
WARNING
! !
Petrol is extremely flammable and is explosive
under certain conditions. Refill in a well
ventilated area with the engine stopped. Do
not smoke or allow flames or sparks in the
area where the vehicle is refilled or where
petrol is stored.
SEAT LOCK
Location : On the rear left side of the seat,
below the rear cowl.
Operation : To unlock the seat, insert the
ignition key (1) and turn in clockwise
direction. To install, engage the hook on the
underside of the seat with the frame and push
on the top rear side of the seat until
the lock clicks.
▲
(1) Ignition key
HELMET HOLDER
The helmet holder is located below the
seat. Remove the seat. Hang the helmet on
the helmet holder (1) by using wire helmet
set (2) (optional). Install the seat (3) and
lock it securely.
1 2
(1) Helmet holder hook
(2) Wire helmet set (optional)
(3) Seat
20
1
3
