Air Cleaner - HERO SPLENDOR iSMART PROGRAMMED FI Manual

Remove the gasket (7) and dowel pins (8).
•
Remove the oil filter screen (9) and wash it
•
in clean non flammable or high flash point
solvent (kerosene).
7
9
(7) Gasket
(9) Oil filter screen
Reinstall the oil filter screen with the sharp
•
edged side facing inwards.
Reinstall the dowel pins, new gasket,
•
crankcase cover, rider footrest assembly
with side stand, exhaust muffler, kick starter
pedal and clutch cable.
Install the side stand switch screw.
•
Adjust the clutch cable free play, if required
•
(page 40).
Fill the crankcase with clean engine oil as
•
per specification.
Ensure to replace gasket with new one once
removed.

AIR CLEANER

Air cleaner element inspection
The air cleaner is viscous paper pleated type
filter which has enhances filtering efficiency.
The air cleaner
intervals
areas, more frequent
necessary.
8
Remove the seat
•
(8) Dowel pins
(1) Air cleaner cover screws
(2) Cover
36
NOTE
should be replaced
(page 28).
When riding in dusty
replacement
(page 20).
2
at regular
may be
1
