HERO SPLENDOR iSMART PROGRAMMED FI Manual page 7

LEFT SIDE VIEW
16
1
(1) Side reflex reflector
(2) Gearshift pedal
(3) Rider footrest
(4) Main stand
(5) Side stand
(6) Battery (inside)
*Accessories and features shown may not be part of standard fitment.
15
2 3 4
(7) Saree guard with women
pillion step
(8) Rear turn signal lamp
(9) Rear reflex reflector
(10) Licence plate lamp
(11) Tail/Stop lamp
3
14
6
5
(12) Rear grip
(13) Seat lock
(14) USB charger (inside)
(optional)
(15) Side stand switch
(16) Front turn signal lamp
