6.6.11 Assembly references

6.6.11.1 Maximum torque values for fasteners
Goulds 2226, 2228, 2229, ASTM A193 B8 and B8M, ASTM A276 Tp 304, ASTM A582 Tp 303, SAE F593
Table 4: 300 Series Stainless Steel Fasteners
Bolt Dia. (D) Tensile Stress
(in.– threads/ Area (Ab), (sq.–
inch) in.)
1/4-20 0.0318
5/16-18 0.0524
3/8–16 0.0775
7/16–14 0.1063
1/2–13 0.1419
9/16–12 0.1819
5/8–11 0.226
3/4–10 0.3345
7/8–9 0.4617
1–8 0.6058
1.125-7 0.7633
1.125-8 0.7904
1.25-7 0.9691
1.25-8 1.000
1.375-6 1.155
1.375-8 1.234
1.5-6 1.405
1.5-8 1.492
1.5-12 1.581
1.625-8 1.775
1.75-5 1.899
1.75-8 2.082
1.875-8 2.414
2-4.5 2.498
2-8 2.771
2.125-8 3.152
2.25-4.5 3.248
2.25-8 3.557
2.375-8 3.987
2.5-4 3.999
2.5-8 4.442
2.625-8 4.921
2.75-4 4.934
3610 i-FRAME API 610 11th Ed/ISO 13709 2nd Ed, API Type BB1 Single-Stage, Axially-Split, Between-Bearing IOM
2226, 2228: 303, 304SS, SAE F593
Group 1 2229: 316SS, SAE F593
Group 2 Yield strength:
65000 psi for 0.25 <=dia<=0.625
45000 psi for 0.75<=dia<=1.5
Torque N-m | ft-lb
Max. preload (lbs) Nickel or Moly Anti-
seize K=0.15
1447 7 | 5
2384 12 | 9
3526 23 | 17
4837 35 | 26
6456 54 | 40
8276 79 | 58
10283 108 | 80
10537 134 | 99
14544 210 | 155
19083 324 | 239
24044 458 | 338
24898 475 | 350
30527 647 | 477
31500 667 | 492
36383 847 | 625
38871 906 | 668
44258 1125 | 830
46998 1194 | 881
49802 1266 | 934
55913 1540 | 1136
59819 1775 | 1309
65583 1946 | 1435
76041 2416 | 1782
78687 2667 | 1967
87287 2958 | 2182
99288 3575 | 2637
102312 3902 | 2878
112046 4272 | 3151
125591 5054 | 3728
125969 5338 | 3937
139923 5929 | 4373
155012 6896 | 5086
155421 7244 | 5343
6.6 Reassembly
A193 B8, B8M Cl 1, A276 Tp 304,
A582 Tp 303
Yield strength=30000 psi
Ultimate tensile=75000 psi
Torque N-m | ft-lb
Max. preload
Nickel or Moly An-
(lbs)
ti-seize K=0.15
668 3 | 2
1100 5 | 4
1628 11 | 8
2232 16 | 12
2980 26 | 19
3820 37 | 27
4746 50 | 37
7025 89 | 66
9696 140 | 103
12722 216 | 159
16029 305 | 225
16598 316 | 233
20351 431 | 318
21000 445 | 328
24255 565 | 417
25914 603 | 445
29505 750 | 553
31332 796 | 587
33201 845 | 623
37275 1026 | 757
39879 1182 | 872
43722 1296 | 956
50964 1611 | 1188
52458 1777 | 1311
58191 1973 | 1455
66192 2384 | 1758
68208 2600 | 1918
74697 2849 | 2101
83727 3371 | 2486
83979 3558 | 2624
93282 3952 | 2915
103341 4598 | 3391
103614 4829 | 3562
